Guangdong LiYou Steel Structure Engineering Co., Ltd. +8619147784007 liyousteelstructure@outlook.com
 |
| Quantity: | |
|---|---|
Steel
Online technical support
Hangar/Shed
Guangdong, China
Hangar
3 years
total solution for projects
GB
1. Galvanized 2. Painted
C.Z Shape Steel Channel
Metal Steel
Single item
1X1X1 cm
1.000 kg
| NO | ITEM | SPECIFICATION | ||||||
| Anchor Bolt and Fastener Parts | Anchor Bolt and Fastener Parts | |||||||
| 1 | Chemical bolt | M16 | ||||||
| 2 | High strength bolt | M20 | ||||||
| 3 | Common bolt | M20 | ||||||
| 4 | Galvanized bolt | M12 | ||||||
| 5 | Turnbuckle bolt | M20 | ||||||
| 6 | Sag rod | ∅12 | ||||||
| 7 | Brace rod | φ32*2.0 round tube | ||||||
| Main Steel Structure Parts | ||||||||
| 1 | Steel column(Q355B) | H500X280X12X16 HN300*150*6*9 | ||||||
| 2 | Wind column(Q355B) | HN300*150*6*9 | ||||||
| 3 | Roof tiny column(Q235B) | HN248X124X5X8 | ||||||
| 4 | Wall connection column(Q235B) | SHS150*150*5.0 | ||||||
| 5 | Roof truss beam（Q355B） | H750~500X220X12X14 H500X220X12X14 H500~750X220X12X14 | ||||||
| 6 | Tie bar(Q235B) | ∅114*3.0 | ||||||
| 7 | Horizontal brace(Q235B) | ∅20 | ||||||
| 8 | Column brace(Q235B) | ∅20 | ||||||
| 9 | Angle brace(Q235B) | L50*4.0 | ||||||
| 10 | Roof purlin (Q355B Galvanized) | C200*70*20*2.2 | ||||||
| 11 | Wall purlin(Q3555B Galvanized) | C160*60*20*2.0 | ||||||
| 12 | Connecting panel(Q355B) | 6mm-20mm | ||||||
| Enclosure structure part | ||||||||
| 1 | Roof panel（BAOSTEEL） | 75mm Thick Type 960 PIR Panels | ||||||
| 2 | Wall sheet（BAOSTEEL） | 0.5mm Thick Type 900 BAOSteel Cladding | ||||||
| 3 | OH DOOR | W4270*H4880*1 | ||||||
| 4 | Gutter | 2mm thick galvanized | ||||||
| 5 | Down spout | TCT Φ 110 with accessories | ||||||
| 6 | Trimming | 0.5mm color steel plate | ||||||
| 7 | Hardware accessories | Nails, supports, structural glue, etc. | ||||||
