| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
More than 5 years
3D model design
LYW-001
Workshop,Plant,Hangar House
Industrial
AutoCAD /PKPM /MTS/3D3S/TARCH
Industrial
Hot-Dip Galvanized,Paint
Q235/Q235B/Q345/Q345B
30-65 Days
Sandwich Panel. Single Steel Sheet
C /Z Purlin
Sliding Door/Rolling Door
Alumiumn Window /3PVC Window
| No | Components | Specification | ||||||
| Embedded Parts | ||||||||
| 1 | Anchor Bolt | M24 | ||||||
| 2 | High Strength Bolt | M20,10.9S | ||||||
| 3 | Common Bolt | M16 | ||||||
| 4 | Galvanized Bolt | M12 | ||||||
| 5 | Shear Nail | M16 | ||||||
| 6 | Tir rod | ∅32*2.5 | ||||||
| Main Steel Structure Parts | ||||||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||||||
| 2 | Wind Column (Q355B) | Wind Column (Q355B) | ||||||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||||||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||||||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||||||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||||||
| 7 | Column Brace (Q235B) | ∅25 | ||||||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||||||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||||||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||||||
| 11 | Connecting Plate | 6mm-30mm | ||||||
| Other Steel Structure Parts | ||||||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||||||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||||||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||||||
| 4 | Down Pipe | PVC160 (Including parts) | ||||||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||||||
