2 Story Steel Building – Fast-Erecting, Cost-Efficient Multi-Level Warehouse Solution
LiYou Steel introduces our innovative 2 story steel building system designed for rapid assembly and superior space efficiency. Our bolt-connected, seldom-welding prefab technology reduces labor costs by up to 40% compared to conventional construction, making it the smart choice for multi-story warehouse and industrial applications.
Easy Erection System
Bolt-together connection design requires minimal skilled labor
Pre-drilled components enable 60% faster installation
No heavy equipment needed for assembly
Smart Structural Design
Pre-engineered steel framing optimized for vertical loading
Integrated mezzanine floor support systems
Optional reinforced platforms for heavy storage
Cost-Saving Features
90% factory prefabrication reduces on-site work
Minimal welding requirements lower labor costs
Reconfigurable design adapts to future needs
Quality Assurance
CE & ISO certified structural components
Hot-dip galvanized steel (optional)
3-stage quality inspection process
| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-001
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
✔ Typical Dimensions: 15-40m span × unlimited length
✔ Clear Height: 6-12m per floor
✔ Loading Capacity: Up to 5kN/m²
✔ Roof/Wall Options:
Single skin corrugated panels
Insulated sandwich panels
Composite cladding systems
Logistics Warehouses: Double your storage capacity
Industrial Plants: Separate production & storage vertically
Retail Distribution: Multi-level fulfillment centers
️ Urban Infill Projects: Maximize small footprints
Why Global Clients Choose Us
✅ 10+ years specializing in multi-story steel structures
✅ Completed projects in USA, Australia, and Southeast Asia
✅ Custom engineering for local building codes
✅ Full-package solutions from design to erection guidance
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
