| Quantity: | |
|---|---|
Steel
Online technical support
Hangar/Shed/Garage
Guangdong, China
Hangar
3 years
total solution for projects
GB
1. Galvanized 2. Painted
Galvanized Steel Frames
C.Z Shape Steel Channel
Color Steel Single Sheets
Two
Steel Structure Frame
Single item
1X1X1 cm
1.000 kg
| NO. | ITEM | SPECIFICATION | ||||||
| Anchor Bolt and Fastener Part | ||||||||
| 1 | Anchor bolt1 | M20*400 | ||||||
| 2 | Anchor bolt2 | M16*260 | ||||||
| 3 | High strength bolt | M20、M16,8.8S | ||||||
| 4 | Common bolt | M16 | ||||||
| 5 | Galvanized bolt | M12 | ||||||
| 6 | Turnbuckle bolt | M16 | ||||||
| 7 | Sag rod | ∅12 | ||||||
| Main Steel Structure Part | ||||||||
| 1 | Steel column（Q235B） | HN396X200X7X11 | ||||||
| 2 | Wind column（Q235B） | SHS150*100*5.0 | ||||||
| 3 | Roof truss beam（Q235B） | HN396X200X7X11 | ||||||
| 4 | Floor main beam（Q235B） | HN600X200X11X17 | ||||||
| 5 | Tie bar（Q235B） | SHS100*100*5.0 | ||||||
| 6 | Horizontal\Column brace(Q235B) | ∅16 | ||||||
| 7 | Steel stairs | [250#、[200#、[160# channel steel、 4mm checkered plate | ||||||
| 8 | Angle brace（Q235B） | L50*6.0 | ||||||
| 9 | Roof purlin（Q355B） | C250X75X20X2.0 | ||||||
| 10 | Wall purlin（Q355B） | C250X75X20X2.0 | ||||||
| 11 | Connecting plate（Q235B） | 6mm-16mm | ||||||
| Enclosure Part | ||||||||
| 1 | Roof plate | 0.6mm thick, type 840 steel sheet | ||||||
| 2 | Exterior wall | 0.6mm thick, type 900 steel sheet | ||||||
| 3 | Steel man door | 910*2010*2 | ||||||
| 4 | Stainless steel handrail | 1.1m high | ||||||
| 5 | Roof ventilator | 600*600 | ||||||
| 6 | Gutter | 2.0mm galvanized | ||||||
| 7 | Downpipe | φ110 PVC | ||||||
| 8 | Trimming | 0.55mm thick steel plate | ||||||
| 9 | Hardware accessories | Nails, supports and structural glue and so on | ||||||
