Liyou Steel delivers high-quality prefabricated metal warehouses designed for storage, logistics, and industrial applications. Our steel structure warehouses combine strength, speed of construction, and cost-efficiency, making them the ideal solution for businesses needing large, secure storage spaces.
✔ Fast Installation – Pre-engineered components allow 50% faster construction vs traditional buildings
✔ Clear-Span Designs (Up to 80m) – Column-free interiors maximize storage space and forklift movement
✔ Extreme Durability – High-strength steel frames withstand heavy snow loads (up to 1.5kN/m²) and strong winds (200km/h)
✔ Low Maintenance – Galvanized steel and optional anti-corrosion coatings ensure long lifespan
✔ Customizable Options – Choose from:
Single or multi-span designs
Various roof styles (single slope, double slope, sawtooth)
Door systems (roller shutters, sliding doors, dock levelers)
Insulation packages for temperature-sensitive goods
| Feature | Specification |
|---|---|
| Frame Material | Q355B structural steel (ASTM A572 equivalent) |
| Column Spacing | 6-9m standard (customizable up to 12m) |
| Wall/Roof Panels | 0.4-0.8mm color steel sheets or insulated sandwich panels |
| Fire Rating | Up to 2 hours with fireproof coatings |
| Design Life | 25-50 years depending on environment |
✅ Logistics & Distribution Centers
✅ Cold Storage Facilities
✅ Manufacturing Storage
✅ Retail & Wholesale Warehouses
✅ Agricultural Storage
Philippines Logistics Hub – 15,000m² steel warehouse (completed in 4 months)
Australian Cold Storage – 8,000m² insulated warehouse (-25°C capability)
US Automotive Parts Warehouse – 12,000m² with 10-ton crane system
20+ Years of steel structure experience
CE, ISO, and SGS certified manufacturing
Turnkey solutions from design to installation
Global delivery to 30+ countries
Get Your Custom Metal Warehouse Quote Today!
→ 3D Design Visualization Available
→ 4-8 Week Production Time
→ 10-Year Structural Warranty
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Steel Frame House |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube etc. | |
Standard: | Type: |
GB | Steel Structure Frame |
Size: | Color: |
Up to Customer's Requirement | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Insulation: |
Sandwich Panel | EPS, Rockwool, Glass wool, PU etc.. |
Door & Windows: | Technology: |
Steel Door, Aluminum Sliding Window, PVC Window | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Big Metal Building Homes |
Components | Specification |
Anchor Bolt | M30 |
High Strength Bolt | M20，10.9S |
Common Bolt | M16 |
Galvanized Bolt | M12 |
Shear Nail | M16 |
Steel Column(Q345B) | HN600X200X10X15 |
Steel Column(Q345B) | HN300X150X6.5X9 |
Roof Column(Q345B) | HN350X175X6X9 |
Floor Main Beam(Q345B) | HN500X200X9X14 |
Floor Second Beam(Q345B) | HN350X175X6X9 |
Stair | ∅16-bar+2.5mm Chequered Plate |
Tie Rod | ∅89*3.0 |
Horizontal Support | ∅16 |
Roof Purlin（Galvanized) | C180*60*20*2.0 |
Wall Purlin（Galvanized) | C180*60*20*2.0 |
Connecting Plate | 6mm～20mm Steel Sheet |
Paint | 2 Times Spray Paint |
Roof Tile- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
FRP Skylight Panel | Fiber Glass Reinforced Polyester |
Outside Wall Panel -- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
Floor Decking | 1.5mm Galvanized Steel Sheet |
Stair Handrail | 口80*40+口40+口30+口20 |
Gutter | 2.0mm Galvanized Gutter |
Down Pipe | ∅110PVC |
Trimming | 1.0mm Galvanized Steel Sheet |
Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Residential House, Airplane Hangar, Outdoor Stadium Shed, Labour Camp, School, Exhibition Hall, Logistics Park, Refrigeration House, Resort, Dormitory Building, Shopping Mall
01 Customized Design
Offer professional building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
Q: What should you provide before quotation?
A: Please send your design drawings, or sketches to us and tell us the materials you want to use. If you do not have the drawings, just inform us more data about the steel building you need, like the building total area, detail dimension, floor amount, roof load, wind load, etc.from all of your requests. If you can make a hand draft, that would be great helpful for us to get your idea.
Q: What accessories do we provide for customized steel buildings?
A: Along with the wall and roof insulation systems, we also offer skylights, commercial-grade ventilation devices such as roof turbine vents and wall louver vents, rolling door, and double sliding doors.
Q: Can the steel building be installed by yourself?
A: Certainly you can. The construction is a simple bolt-together process, which is easy if you have the needed access equipment. Every steel building we make comes with bolts, screws, downspout, gutters, flashing and clear instructions as to show you where everything is to be installed. And we will provide the installation drawing to you for reference.
Q: What should be prepared for the site before installation?
A: You will need concrete piers for the columns to sit upon. Most people pour a full foundation, but if your steel building is on a farm or ranch and there will be dirt, gravel, or sawdust on floors, a pier system may be preferable. In these situations, the popular option is to combine piers with a concrete footing around the perimeter of the building.
Q: Do we have a recommended foundation and associated drawing?
A: Yes, we will provide the foundation drawing and the installation drawing for you after shipment. But the foundation drawing is just for reference because the land and the soil are different in different countries.
