Liyou delivers high-quality light gauge steel buildings for residential, commercial, and industrial applications. Our precision-engineered structures offer superior strength, design flexibility, and faster construction compared to traditional materials.
✔ Lightweight Yet Strong – High tensile strength with reduced structural weight
✔ Faster Construction – Prefabricated components for quick assembly
✔ Design Flexibility – Custom layouts for homes, offices, and multi-story buildings
✔ Fire & Termite Resistant – Non-combustible and durable
✔ Eco-Friendly – 100% recyclable with minimal construction waste
Residential: Villas, apartments, modular homes
Commercial: Hotels, retail spaces, offices
Institutional: Schools, clinics, community centers
Get a Custom Solution Today!
✅ LEED-Certified Options | ✅ Cost-Effective Pricing | ✅ Global Delivery
| Quantity: | |
|---|---|
Steel
Online technical support
Office Building
Guangdong, China
Steel Structure
3 years
total solution for projects
Office
Modern
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
A light gauge steel building is built with thin-gauge, cold-formed steel members that are manufactured in a controlled factory environment and assembled on site.
This building system focuses on:
Lightweight structural design
High strength-to-weight ratio
Precision fabrication
Fast and efficient installation
It is an alternative to traditional concrete or heavy steel structures.
A standard light gauge steel building includes:
Wall Framing: Light gauge steel studs and tracks
Floor System: Steel joists and decking
Roof Structure: Trusses or light steel rafters
Enclosure System: Boards or panel systems
Connections: Bolted or screwed steel joints
All components are engineered according to design loads and building codes.
Lightweight structure reduces foundation loads
Factory-controlled fabrication improves accuracy
Faster installation compared with traditional methods
Flexible architectural design options
Reduced material waste on site
These advantages make light gauge steel buildings suitable for modern construction projects.
| No. | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
A light gauge steel building is built with thin-gauge, cold-formed steel members that are manufactured in a controlled factory environment and assembled on site.
This building system focuses on:
Lightweight structural design
High strength-to-weight ratio
Precision fabrication
Fast and efficient installation
It is an alternative to traditional concrete or heavy steel structures.
A standard light gauge steel building includes:
Wall Framing: Light gauge steel studs and tracks
Floor System: Steel joists and decking
Roof Structure: Trusses or light steel rafters
Enclosure System: Boards or panel systems
Connections: Bolted or screwed steel joints
All components are engineered according to design loads and building codes.
Lightweight structure reduces foundation loads
Factory-controlled fabrication improves accuracy
Faster installation compared with traditional methods
Flexible architectural design options
Reduced material waste on site
These advantages make light gauge steel buildings suitable for modern construction projects.
| No. | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
