Guangdong LiYou Steel Structure Engineering Co., Ltd. +8619147784007 liyousteelstructure@outlook.com
 |
| Quantity: | |
|---|---|
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Light Steel Villa |
Material: | Standard: |
Q235 Square Tube, H Section Steel, C/Z Section Steel, Steel Keel etc. | GB |
Type: | Use: |
Light Steel Structure Frame | Residence, Tourist and Holiday House, Real Estate Development Project |
Size: | Roof & Wall Material: |
Up to Customer's Requirement | Fiber Cement Board or Cement Board+Glass Wool |
Window: | Door: |
Aluminum Alloy Window/PVC Windows | Steel / Aluminum Door |
Roof & Wall Material: | Roof & Wall Material: |
Roof tile-Asphalt shingles/Resin tile | Wall cladding-Cement wall cladding/ PVC wall cladding, etc |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Steel Structure Villa |
Components | Specification |
Embedded parts | |
Expansion bolt | M12 |
Expansion bolt | M8 |
Galvanized bolt | M12 |
Self-tapping screw | M5 |
Main steel frame | |
Steel column(Q235B) | 口100*2.0 |
Roof trust beam(Q235B) | 口80*40+口80*40 |
Bottom beam(Q235B) | 口150*100*2.5 |
Bottom purlin(Q235B) | 口100*50*2.0 |
Ring beam | 口100*1.8 |
Roof purlin | 口80*40*1.8 |
Connecting plate | 6mm-10mm |
Structure steel fabrication+Resist rust+Painting | |
Maintenance | |
Roof tile | 2.5 mm Resin tile |
Waterproof material | Asphalt |
Roof panel | 15 mm plywood |
Outside wall panel | 100mm fiber cement board |
Partition wall panel | 100mm fiber cement board |
Flooring | 20mm calcium silicate board |
Outside deck flooring | WPC decking |
Balcony ceiling | 6mm calcium silicate board+steel keel+ bracing |
Steel door | W900*H2050 |
Aluminum swing door | W800*H2050 |
Aluminum sliding window | W800*H600 |
Aluminum sliding window | W1200*H1000 |
Aluminum sliding window | W1600*H800 |
Handrail, fence | 口80*40+口40+口20 |
Trimming | GRC 59m Galvanized plate, color steel sheet:103m |
● The flexible interior partition can make good use of the space.
● Resource-efficient practices produce less waste and less impact on the environment.
● Steel structure construction is strong, durability and stability.
● The prefabricated or modular building can be on job sites anywhere.
● Varied designs, luxurious appearance, good comfort, and energy saving.
● The service life is long and more than 30 years.
● Fast construction, easy installation, and convenient to transport.
The light steel villa is widely used in the construction of buildings, such as residence, tourist and holiday house, family house, government residential project real estate development project, etc.
Foshan Teamwork Steel Structure Co.,Ltd was found in 2008. We are specialized in designing, manufacturing, marketing and construction of the steel structure warehouse, steel structure workshop, prefabricated house and light steel villa.
Teamwork Steel Structure have two production workshops covering an area of 20000 square meters. One plant is in LiShui Town, Foshan, which mainly produces prefab house, fence, aluminum door, and window. The other one is located in Gaoming district, Foshan which mainly produces prefab steel structure building. With the modern advanced facility, we have the capability to manufacture 30000~50000 sqm per month.
01 Customized Design
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
1. Project Dimension
Width__________meters, Length________meters, Height__________meters
2. Roof Slop Grade___________
3. Wall Panel: Fiber Cement Board, Thickness:___________
4. Wall Decoration: Cement Cladding, Metal Cladding, PVC Cladding etc.
5. Roof Panel: EPS / PU / Rockwool Sandwich Panel, Thickness:__________________
6. Roof Decoration: Asphalt Single / Resin Tile / Metal Tile
7. Door: 1)Aluminium Sliding Door 2) Steel Door 3) Roll Up Door(garage), Size :________
8. Window: 1)Aluminium Window 2)PVC Window, Size :______________
9. Draining: 1)Natural draining 2)Gutter+Downspout
