At LiYou Steel Structure Engineering, we engineer roof structure steel systems that combine lightweight durability with superior load-bearing capacity. Our steel roof frameworks are 30% lighter yet 50% stronger than traditional wood trusses, making them ideal for industrial plants, commercial complexes, and architectural landmarks worldwide.
Availability: | |
---|---|
Quantity: | |
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
garage shed, storage closet, poultry houses, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard, Other, Kitchen, Bathroom, Home Office, Living Room, Bedroom, Dining, Babies and kids, Outdoor, Storage & Closet, Exterior, Wine Cellar, Entry, Hall, Home Bar, Staircase, Basement, Garage & Shed, Gym, Laundry
steel
Guangdong, China
Modern
Lifetime
Liyou
LYB-001
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Unmatched Strength-to-Weight Ratio
Clear spans up to 80m without intermediate supports
Snow load capacity: 150 psf (7.2 kPa)
Wind resistance: Rated for Category 4 hurricanes
Precision-Engineered Components
Pre-fabricated trusses with ±2mm tolerance
Cold-formed purlins (Z-shape/C-shape)
Galvanized coatings (G90 standard)
Fast Installation
Bolt-up systems reduce construction time by 40%
Pre-welded nodes for field assembly efficiency
Custom Design Options
Curved barrel vaults for stadiums
Sawtooth profiles for industrial daylighting
Green roof-ready reinforcement
✅ Material Certifications
ASTM A653 (Galvanized steel)
EN 10147 (Pre-painted coils)
AS/NZS 1163 (Australia/NZ compliance)
✅ Smart Roof Innovations
Integrated solar panel mounts
Thermal break technology (U-value 0.25 W/m²K)
Acoustic dampening (STC 45 rating)
✅ Global Project Experience
Philippine Airport Terminal: 18,000m² standing seam roof
Dubai Mall Extension: 500-ton space frame canopy
Canadian Distribution Center: 12° slope snow-shedding design
No | Components | Specification | ||
Embedded Parts | ||||
1 | Anchor Bolt | M24 | ||
2 | High Strength Bolt | M20,10.9S | ||
3 | Common Bolt | M16 | ||
4 | Galvanized Bolt | M12 | ||
5 | Shear Nail | M16 | ||
6 | Tir rod | ∅32*2.5 | ||
Main Steel Structure Parts | ||||
1 | Steel Column (Q355B) | H550*300*10*16 | ||
2 | Wind Column (Q355B) | H400*220*6*10 | ||
3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
5 | Tie Bar(Q235B) | ∅168*4.0 | ||
6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
7 | Column Brace (Q235B) | ∅25 | ||
8 | Angle Brace (Q235B) | L63*5.0 | ||
9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
11 | Connecting Plate | 6mm-30mm | ||
Other Steel Structure Parts | ||||
1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
3 | Gutter | 2mm Galvanized Steel Plate | ||
4 | Down Pipe | PVC160 (Including parts) | ||
5 | Trimming | Color steel 0.5mm Gavanized steel panel |
