Liyou specializes in Steel I Beam Building construction, offering custom, durable steel structures designed for various applications. With years of expertise in steel structure fabrication, we deliver cost-effective solutions that stand the test of time.
Dimensions: Fully customizable steel I beams and frame sizes to suit your building requirements.
Finishing: Available in galvanized, powder-coated, or painted finishes for added protection against corrosion.
Insulation: Optional energy-efficient panels for better thermal performance and comfort.
Load-Bearing Capacity: Designed to support heavy loads and withstand harsh environmental conditions.
| Quantity: | |
|---|---|
Steel
Online technical support
Industrial Building
Guangdong, China
Industrial Area
3 years
total solution for projects
LYB-001
Steel
Industrial
Guangdong
CE Certification
C.Z Shape Steel Channel
Customized Color
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
Primer and Top
Customized
Industrial Commercial
25-60 days
Single item
1X1X1 cm
1.000 kg
A steel I beam building is a high-strength steel structure that uses I-shaped steel beams as the primary load-bearing elements. This design provides excellent structural integrity, long spans without interior columns, and resistance to heavy loads, making it ideal for industrial facilities, warehouses, aircraft hangars, and commercial buildings.
Prefabricated components allow for faster construction, lower labor costs, and minimal maintenance, providing a cost-effective solution for projects requiring durable, flexible, and long-lasting steel buildings.
High Load-Bearing Capacity: I beams provide exceptional strength and stability for heavy-duty applications.
Wide Clear Spans: Large open interiors with minimal columns for flexible usage.
Durable Materials: Steel frames resist corrosion, fire, and pests, ensuring long-term performance.
Prefabricated Components: Factory-fabricated beams, trusses, and columns for fast, reliable assembly.
Customizable Layouts: Adaptable widths, lengths, and heights for various industrial and commercial needs.
Versatile Applications: Warehouses, manufacturing facilities, hangars, workshops, and storage buildings.
| Component | Description |
|---|---|
| I Beams | Primary structural elements supporting roof and walls |
| Steel Columns & Trusses | Engineered for wide spans and heavy loads |
| Roof Panels | Corrugated or insulated steel panels for durability and weather protection |
| Wall Panels | Standard or insulated steel siding for strength and insulation |
| Optional Features | Doors, windows, skylights, ventilation, and mezzanine floors |
Site Preparation: Clear and level the site; lay foundation.
Frame Assembly: Erect steel I beams, columns, and trusses according to design.
Roof & Wall Installation: Attach panels, insulation, and optional features.
Inspection & Safety Check: Verify all connections and structural integrity.
Completion: Steel I beam building ready for industrial, commercial, or storage use.
Warehouses & Storage Buildings: Maximize open interior space with column-free design.
Industrial & Manufacturing Facilities: Support heavy machinery and operations.
Aircraft Hangars & Workshops: Wide spans suitable for planes, vehicles, and large equipment.
Commercial Buildings: Flexible layouts for retail, office, or mixed-use industrial projects.
Size & Layout: Width, length, and height customizable according to project requirements.
Roof & Wall Options: Gable, arched, or flat roofs; insulated or standard wall panels.
Optional Features: Doors, windows, ventilation, lighting, and mezzanine floors.
Request a Quote: Submit your specifications to get a personalized steel I beam building quote.
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
A steel I beam building is a high-strength steel structure that uses I-shaped steel beams as the primary load-bearing elements. This design provides excellent structural integrity, long spans without interior columns, and resistance to heavy loads, making it ideal for industrial facilities, warehouses, aircraft hangars, and commercial buildings.
Prefabricated components allow for faster construction, lower labor costs, and minimal maintenance, providing a cost-effective solution for projects requiring durable, flexible, and long-lasting steel buildings.
High Load-Bearing Capacity: I beams provide exceptional strength and stability for heavy-duty applications.
Wide Clear Spans: Large open interiors with minimal columns for flexible usage.
Durable Materials: Steel frames resist corrosion, fire, and pests, ensuring long-term performance.
Prefabricated Components: Factory-fabricated beams, trusses, and columns for fast, reliable assembly.
Customizable Layouts: Adaptable widths, lengths, and heights for various industrial and commercial needs.
Versatile Applications: Warehouses, manufacturing facilities, hangars, workshops, and storage buildings.
| Component | Description |
|---|---|
| I Beams | Primary structural elements supporting roof and walls |
| Steel Columns & Trusses | Engineered for wide spans and heavy loads |
| Roof Panels | Corrugated or insulated steel panels for durability and weather protection |
| Wall Panels | Standard or insulated steel siding for strength and insulation |
| Optional Features | Doors, windows, skylights, ventilation, and mezzanine floors |
Site Preparation: Clear and level the site; lay foundation.
Frame Assembly: Erect steel I beams, columns, and trusses according to design.
Roof & Wall Installation: Attach panels, insulation, and optional features.
Inspection & Safety Check: Verify all connections and structural integrity.
Completion: Steel I beam building ready for industrial, commercial, or storage use.
Warehouses & Storage Buildings: Maximize open interior space with column-free design.
Industrial & Manufacturing Facilities: Support heavy machinery and operations.
Aircraft Hangars & Workshops: Wide spans suitable for planes, vehicles, and large equipment.
Commercial Buildings: Flexible layouts for retail, office, or mixed-use industrial projects.
Size & Layout: Width, length, and height customizable according to project requirements.
Roof & Wall Options: Gable, arched, or flat roofs; insulated or standard wall panels.
Optional Features: Doors, windows, ventilation, lighting, and mezzanine floors.
Request a Quote: Submit your specifications to get a personalized steel I beam building quote.
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
