Since 2014, Guangdong LiYou has been a trusted manufacturer of steel parking structure, delivering durable, cost-effective, and customizable solutions for commercial, industrial, and public applications. We combine advanced engineering, high-grade materials, and global project experience to provide reliable parking solutions worldwide.
✅ Robust & Long-Lasting Construction
Material: High-strength steel with hot-dip galvanized anti-corrosion treatment
Structural Design: Engineered using SAP2000, AutoCAD, TEKLA for optimal load-bearing capacity
Durability: Resists weather, UV exposure, and heavy vehicle loads
✅ Customizable & Scalable Designs
Single or Multi-Level Parking Solutions
Clear-Span Designs (up to 60m+ for unobstructed space)
Aesthetic Flexibility: Custom colors & finishes to match architectural needs
✅ Fast Installation & Cost Efficiency
Prefabricated Components for quick on-site assembly
25-60 Days Delivery (faster than traditional construction)
Low Maintenance – Reduced long-term operational costs
✅ Safety & Compliance
CE Certified – Meets European structural standards
Wind & Seismic Resistant – Suitable for extreme climates
Slip-Resistant Flooring Options – Enhanced safety for drivers & pedestrians
✔ Model: LYB-001 (Custom designs available)
✔ Frame: High-strength steel columns & beams
✔ Roofing & Cladding: Optional sandwich panels for insulation & weather protection
✔ Accessories:
Sliding Doors for vehicle entry/exit
Aluminum Alloy Windows for natural lighting
C/Z Purlin System for reinforced stability
✔ Warranty: 3-year quality guarantee
Our steel parking structure have been successfully installed in:
Commercial Hubs (Shopping malls, office complexes)
Public Infrastructure (Airports, train stations, hospitals)
Industrial Facilities (Factory parking, logistics hubs)
Countries Served: Philippines, USA, Canada, Australia, Mexico, Kazakhstan, Zambia & more.
| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-001
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
