Liyou stands at the forefront of steel structures fabrication, delivering high-performance structural systems tailored for demanding construction environments. Our commitment to innovation, accuracy, and global standards allows us to fabricate reliable steel components that form the backbone of buildings across industries.
Liyou's fabricated steel structures are widely used in:
Industrial Projects: Manufacturing plants, production bases, machinery workshops.
Warehousing: Bulk storage buildings, logistic hubs, dry goods shelters.
Public Infrastructure: Stations, terminals, overpasses, and support platforms.
Agriculture: Grain depots, equipment garages, livestock enclosures.
Commercial Facilities: Large exhibition centers, pavilions, and retail buildings.
Advanced Manufacturing Facilities: Equipped with automated production lines for consistent and scalable output.
Customization Without Limits: From layout to material to finish, every detail is designed around your needs.
Cost-Efficiency with Quality: Our pricing remains competitive without cutting corners on performance or safety.
Comprehensive Project Support: We assist with technical drawings, installation guidance, and post-sale service.
| Quantity: | |
|---|---|
Steel
Online technical support
Metal Recycling Plant
Guangdong, China
Industrial Area
3 years
total solution for projects
LYB-001
Metal Recycling Plant
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
