Types of Joints in Steel Structures


Steel structures rely on strong, well-designed joints to ensure stability, durability, and load-bearing efficiency. At LiYou Steel Structure Engineering Co., Ltd., we specialize in high-quality steel construction, including various types of joints in steel structures tailored for industrial, commercial, and infrastructure projects. Below, we explore the most common steel structure joints and their applications.

Availability:
Quantity:
  • Steel

  • Online technical support

  • Workshop

  • Guangdong, China

  • Industrial Area

  • 3 years

  • total solution for projects

  • LYB-001

  • Workshop

  • Industrial

  • CE Certification

  • Industrial Commercial

  • C.Z Shape Steel Channel

  • Sliding Door

  • Customized Color

  • Sandwich Panel Optional

  • Aluminum Alloy Sliding Window

  • SAP2000/AutoCAD /PKPM /3D3S/TEKLA

  • Hot Dip Galvanized

  • 25-60 days

  • Single item

  • 1X1X1 cm

  • 1.000 kg

Types of Joints in Steel Structures – A Comprehensive Guide


1. Welded Joints

Description: Permanent connections formed by melting and fusing steel components.
Advantages:
✔ High strength & rigidity
✔ Seamless appearance
✔ Ideal for heavy-load structures
Applications: Bridges, high-rise buildings, and industrial plants.

2. Bolted Joints

Description: Components fastened using high-tensile bolts and nuts.
Advantages:
✔ Easy assembly & disassembly
✔ Adjustable for on-site modifications
✔ Cost-effective for large-scale projects
Applications: Prefabricated warehouses, stadiums, and modular buildings.

3. Riveted Joints (Traditional)

Description: Historical method using hot-driven rivets (less common today).
Advantages:
✔ Excellent vibration resistance
✔ Long-term durability
Applications: Heritage structures and heavy machinery supports.

4. Pinned (Hinged) Joints

Description: Allows rotational movement, reducing stress from thermal expansion.
Advantages:
✔ Flexibility under dynamic loads
✔ Prevents structural deformation
Applications: Truss systems, bridges, and seismic-resistant designs.

5. Moment-Resisting Joints

Description: Rigid connections that resist bending forces.
Advantages:
✔ Enhanced structural stability
✔ Used in earthquake-prone zones
Applications: Skyscrapers, industrial frames, and cantilevered structures.


Why Choose LiYou Steel for Steel Structure Joints?

✅ Expert Engineering – Our team designs joints for optimal load distribution.
✅ Quality Assurance – Compliance with CE, ISO, and SGS standards.
✅ Global Experience – Successful projects in the USA, Australia, Africa, and Southeast Asia.

PRODUCT SPECIFICATIONS
No
Components
Specification
Embedded Parts
1
Anchor Bolt
M24
2
High Strength Bolt
M20,10.9S
3
Common Bolt
M16
4
Galvanized Bolt
M12
5
Shear Nail
M16
6
Tir rod
∅32*2.5
Main Steel Structure Parts
1
Steel Column (Q355B)
H550*300*10*16
2
Wind Column (Q355B)
H400*220*6*10
3
Roof Frame Beam (Q355B)
H900~500*220*10*12 H500~650*220*8*12
4
Crane Beam (Q355B)
H650*320/240*10*16/14
5
Tie Bar(Q235B)
∅168*4.0
6
Horizontal Brace (Q235B)
∅168*4.0
7
Column Brace (Q235B)
∅25
8
Angle Brace (Q235B)
L63*5.0
9
Roof Purlin (Galvanized)
Z280*80*20*2.5
10
Wall Purlin (Galvanized)
C250*75*20*2.5
11
Connecting Plate
6mm-30mm
Other Steel Structure Parts
1
Roof Panel
50mm Rock wool Sandwich panel
2
Wall Panel
50mm Rock wool Sandwich panel
3
Gutter
2mm Galvanized Steel Plate
4
Down Pipe
PVC160 (Including parts)
5
Trimming
Color steel 0.5mm Gavanized steel panel
