As a premier China steel frame warehouse manufacturer, Liyou Steel specializes in fully customized steel warehouses designed to meet your specific storage needs, local climate challenges, and operational requirements. Our engineer-to-order approach ensures you get a high-performance warehouse with optimal space utilization and durability.
| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-001
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
✔ 100% Custom Design Service
Span widths: 15m to 60m+ (column-free spaces)
Eave heights: 5m to 15m+ (for racking systems)
Custom door configurations (roll-up, sliding, or sectional)
Mezzanine floors & crane beam options
✔ Superior Structural Performance
Wind resistance: Up to 200km/h
Snow load capacity: 1.5kN/m² standard (higher available)
Seismic resistance: 8-degree fortification
✔ Smart Warehouse Features
Natural lighting systems (skylight panels)
Ventilation & insulation packages
LED lighting-ready designs
Future expansion provisions
Requirement Analysis
Storage volume & equipment needs
Local climate & seismic conditions
Fire safety & building code compliance
Engineering Design
3D modeling (Tekla/BIM)
Load calculations & structural analysis
Approval drawings within 7 working days
Precision Fabrication
CNC cutting (±1mm tolerance)
Automated welding (ISO 3834 certified)
Hot-dip galvanizing (80-120μm coating)
Global Delivery & Installation
Component labeling for easy assembly
Optional on-site technical guidance
Turnkey solutions available
| Parameter | Standard Specification | Custom Options |
|---|---|---|
| Frame Material | Q355B steel | ASTM A572, EN 10025 |
| Roof/Wall Panel | 0.5mm corrugated | Insulated sandwich panels |
| Design Life | 50 years | Extended coatings available |
| Fire Rating | Class B1 standard | Class A upgrades |
E-commerce Fulfillment Center (Vietnam)
18,000m² clear-span warehouse
12m eave height for automated racking
Completed in 20 weeks
Cold Storage Facility (Philippines)
8,000m² with 100mm insulated panels
-25°C temperature maintenance
Energy-saving design
✅ Cost Savings: 30-40% vs. traditional construction
✅ Faster Completion: 50% quicker than concrete buildings
✅ Quality Assurance: CE, ISO, and SGS certified
✅ After-Sales Support: 10-year structural warranty
Start Your Custom Warehouse Project Today!
Send us your site details and requirements
Receive preliminary design and quote within 5 days
Approve final engineering drawings
15+ Years warehouse fabrication experience
200+ successful warehouse projects
50+ Countries served
1-Stop Solution from design to installation
Request Your Custom Warehouse Plan Now!
✅ Free initial design consultation
✅ Competitive factory-direct pricing
✅ Professional installation guidance
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
