Lower Carbon Footprint:
Cantilever shade structure steel is a modern and versatile solution for creating durable, open, and aesthetically appealing shaded areas without obstructing the space beneath. Designed to combine strength, flexibility, and architectural elegance, cantilever steel structures are ideal for commercial plazas, parks, walkways, parking areas, and recreational spaces. Liyou's cantilever steel solutions are engineered to withstand harsh outdoor conditions while offering customizable designs that integrate seamlessly with your environment.
Robust Structural Strength: Supports wide spans without intermediate columns, ensuring open and unobstructed spaces.
Flexible Design Options: Customizable sizes, shapes, and finishes to meet unique architectural needs.
Easy Installation: Prefabricated components designed for efficient assembly on-site.
Aesthetic Appeal: Sleek and modern designs that enhance the visual impact of outdoor spaces.
Custom Solutions: Cantilever structures designed to meet the unique needs of each project
Global Expertise: Proven experience delivering steel shade structures worldwide
Quality Focus: Rigorous control throughout design, fabrication, and installation processes
Competitive Value: High-quality solutions at cost-effective pricing
Comprehensive Support: From design consultation to shipping and on-site assembly, Liyou provides end-to-end assistance
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
