Liyou is your go-to source for premium insulated steel buildings. Since our establishment in 2014, we've been delivering top-tier, energy-efficient steel structures to meet a wide range of client needs. Our insulated buildings combine the best in strength and insulation technology, ensuring maximum comfort, energy savings, and structural reliability across various industries.
Durability: Resistant to harsh weather conditions, corrosion, and wear, ensuring long-term performance even in extreme environments.
Customizable Designs: Flexible dimensions and insulation options tailored to suit your specific needs, including thermal, acoustic, and fire-resistant properties.
Fast Construction: Pre-engineered components allow for rapid assembly, reducing project timelines and labor costs.
Low Maintenance: Thanks to the high-quality steel and superior insulation, these buildings require minimal upkeep over their lifetime.
Material: High-strength galvanized steel.
Insulation: Available in a variety of materials including PIR, PUR, and fiberglass for optimal thermal and sound insulation.
Frame: Robust welded steel frame, engineered for long-lasting stability.
Fire Resistance: Insulated panels designed to provide a higher degree of fire resistance.
Dimensions: Fully customizable based on project requirements.
Wind & Load Capacity: Designed to handle high wind loads and heavy snow accumulation.
Availability: | |
---|---|
Quantity: | |
Steel
Online technical support
Metal Frame School/Classroom Project
Guangdong, China
Industrial Area
3 years
total solution for projects
LYB-001
Metal Frame School/Classroom Project
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
No. | Components | Specification | ||
Embedded Parts | ||||
1 | Anchor Bolt | M24 | ||
2 | High Strength Bolt | M20,10.9S | ||
3 | Common Bolt | M16 | ||
4 | Galvanized Bolt | M12 | ||
5 | Shear Nail | M16 | ||
6 | Tir rod | ∅32*2.5 | ||
Main Steel Structure Parts | ||||
1 | Steel Column (Q355B) | H550*300*10*16 | ||
2 | Wind Column (Q355B) | H400*220*6*10 | ||
3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
5 | Tie Bar(Q235B) | ∅168*4.0 | ||
6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
7 | Column Brace (Q235B) | ∅25 | ||
8 | Angle Brace (Q235B) | L63*5.0 | ||
9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
11 | Connecting Plate | 6mm-30mm | ||
Other Steel Structure Parts | ||||
1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
3 | Gutter | 2mm Galvanized Steel Plate | ||
4 | Down Pipe | PVC160 (Including parts) | ||
5 | Trimming | Color steel 0.5mm Gavanized steel panel |
