Guangdong LiYou Steel Structure Engineering Co., Ltd. +8619147784007 liyousteelstructure@outlook.com
 |
| Quantity: | |
|---|---|
steel
Guangdong, China
Modern
Lifetime
Liyou
LYB-001
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
An LGS building uses cold-formed light gauge steel sections as its primary structural components.
These steel members are factory-produced and assembled on site to form walls, floors, and roof systems.
Compared with traditional concrete or heavy steel structures, LGS buildings focus on:
Lightweight structural design
High dimensional accuracy
Modular and prefabricated construction
Faster installation timelines
LGS buildings are commonly used for:
Residential houses and villas
Apartment buildings and dormitories
Commercial buildings and offices
Hotels, resorts, and modular housing
Schools and healthcare facilities
They are especially suitable for low-rise to mid-rise construction projects.
A standard LGS building system includes:
Wall Framing: Light gauge steel studs and tracks
Floor System: Steel joists and decking
Roof Framing: Trusses or light steel rafters
Sheathing: Boards or panels for enclosure
Connection System: Bolted or screwed joints
All components are designed according to structural loads and building codes.
Lightweight structure with high strength-to-weight ratio
Faster construction compared with traditional methods
Factory-controlled fabrication ensures consistency
Flexible architectural design options
Reduced on-site labor and material waste
These benefits make LGS buildings a popular solution for modern construction.
LGS buildings can be customized based on project requirements:
Building layout and floor plans
Number of floors and structural loads
Climate and environmental conditions
Integration with insulation and finishing systems
Technical support is provided to ensure the building meets local standards and functional needs.
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
