Light Steel Frame House Plans

Transform your residential vision with our innovative light steel frame house plans - the modern alternative to traditional construction. LiYou's light gauge steel framing systems combine architectural flexibility with unmatched structural performance for homes that last generations.

Our steel frame house plans offer:

  • 30-50% faster construction than conventional methods

  • 100% termite-proof and non-combustible materials

  • Design flexibility for contemporary or traditional aesthetics

  • Sustainable construction with 90% recyclable materials

Key features of our light steel frame homes:

  1. Precision Engineering: Every component is CAD-designed and factory-prefabricated within 1mm tolerances

  2. Energy Efficiency: Integrated insulation systems outperform wood-frame homes by 40%

  3. Disaster Resistance: Proven performance in seismic zones and hurricane regions

Popular light steel frame house plans configurations:

  • Modern minimalist villas (200-400 sqm)

  • Multi-story townhomes

  • Modular vacation homes

  • Luxury eco-residences

Project Spotlight:
Australian Residential Project
• 5360 sqm area | 390 tons steel
• Completed in just 4 months
• Withstood Category 4 cyclones

Our light steel frame design process:

  1. Conceptual sketches based on your requirements

  2. 3D modeling and engineering calculations

  3. Material optimization and fabrication

  4. Step-by-step installation guidance

Why global homeowners choose our steel frame house plans:
✔ International building code compliance
✔ 50-year structural warranty
✔ Cost savings on maintenance
✔ Shorter construction timelines

Request our light steel frame house plans portfolio today to see how we're redefining modern residential construction across four continents.


Cow Shedcustomized Metal Sheds Prefab Steel Warehousecustom-design Steel Structure Warehouse

Availability:
Quantity:
  • Steel

  • Online technical support

  • Warehouse

  • Guangdong, China

  • Warehouse

  • 3 years

  • total solution for projects

  • LYB-001

  • Warehouse

  • Industrial

  • CE Certification

  • Industrial Commercial

  • C.Z Shape Steel Channel

  • Sliding Door

  • Customized Color

  • Sandwich Panel Optional

  • Aluminum Alloy Sliding Window

  • SAP2000/AutoCAD /PKPM /3D3S/TEKLA

  • Hot Dip Galvanized

  • 25-60 days

  • Single item

  • 1X1X1 cm

  • 1.000 kg


PRODUCT SPECIFICATIONS
No.
Components
Specification
Embedded Parts
1
Anchor Bolt
M24
2
High Strength Bolt
M20,10.9S
3
Common Bolt
M16
4
Galvanized Bolt
M12
5
Shear Nail
M16
6
Tir rod
∅32*2.5
Main Steel Structure Parts
1
Steel Column (Q355B)
H550*300*10*16
2
Wind Column (Q355B)
H400*220*6*10
3
Roof Frame Beam (Q355B)
H900~500*220*10*12 H500~650*220*8*12
4
Crane Beam (Q355B)
H650*320/240*10*16/14
5
Tie Bar(Q235B)
∅168*4.0
6
Horizontal Brace (Q235B)
∅168*4.0
7
Column Brace (Q235B)
∅25
8
Angle Brace (Q235B)
L63*5.0
9
Roof Purlin (Galvanized)
Z280*80*20*2.5
10
Wall Purlin (Galvanized)
C250*75*20*2.5
11
Connecting Plate
6mm-30mm
Other Steel Structure Parts
1
Roof Panel
50mm Rock wool Sandwich panel
2
Wall Panel
50mm Rock wool Sandwich panel
3
Gutter
2mm Galvanized Steel Plate
4
Down Pipe
PVC160 (Including parts)
5
Trimming
Color steel 0.5mm Gavanized steel panel
