| Quantity: | |
|---|---|
Workshop
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
Steel Workshop, garage shed, storage closet, buildings prefab workshop, steel warehouse, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard, Other, Kitchen, Bathroom, Home Office, Living Room, Bedroom, Dining, Babies and kids, Outdoor, Storage & Closet, Exterior, Wine Cellar, Entry, Hall, Home Bar, Staircase, Basement, Garage & Shed, Gym, Laundry
Modern
Guangdong, China
Lifetime
engineer guidance
Liyou
LY001
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
Superior Structural Integrity
Clear spans up to 150m without interior columns
Wind resistance up to 200 km/h (125 mph)
Seismic performance for high-risk zones
Snow load capacity up to 1.5 kN/m² (30 psf)
Cost-Effective Construction
30-50% faster erection than traditional construction
Lower foundation costs due to lightweight design
Reduced long-term maintenance expenses
Design Flexibility
Customizable dimensions and configurations
Multiple roof styles (gable, single slope, etc.)
Various exterior finish options
Premium Materials
High-grade steel (Q235B/Q355B)
Hot-dip galvanized or painted finishes
Optional insulated panels for energy efficiency
Quality Assurance
ISO 9001 certified manufacturing
CE, ASTM, and GB standard compliant
10-year structural warranty
| Component | Specification |
|---|---|
| Primary Framing | Welded rigid frames, 12-22 gauge |
| Secondary Framing | Z/C purlins & girts, 14-20 gauge |
| Roof System | 32mm standing seam or corrugated panels |
| Wall System | Insulated or non-insulated metal panels |
| Doors/Windows | Custom sizes and configurations |
| Finish Options | 20+ color choices, various textures |
Basic Industrial Buildings
$XX-XX/sq.ft. (500-5,000 sq.ft.)
Includes: Primary framing, roof/wall panels, basic trim
Standard Commercial Buildings
$XX-XX/sq.ft. (5,000-25,000 sq.ft.)
Includes: Insulated panels, architectural finishes
Custom Architectural Structures
$XX-XX/sq.ft. (25,000+ sq.ft.)
Includes: Special engineering, premium finishes
Note: Final pricing depends on project specifics including location, design complexity, and current material costs.
Consultation & Design
Free initial consultation
Custom engineering drawings
Permit documentation assistance
Precision Manufacturing
CNC cutting (±1mm tolerance)
Robotic welding for consistent quality
Complete quality inspections
Efficient Installation
Bolt-together connections
Experienced erection crews
Turnkey construction available
Warehouses & Distribution Centers
Manufacturing Facilities
Aircraft Hangars
Retail & Commercial Buildings
Agricultural Storage
Recreational Facilities
Request a Free Quote: Contact us today for a customized price estimate based on your project requirements. Our team will provide detailed specifications and competitive pricing for your metal building structure project.
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
