Lower Carbon Footprint:
Liyou has been at the forefront of providing high-quality prefab metal solutions since 2014. We specialize in designing, fabricating, and delivering prefab metal buildings and structural components that are both durable and cost-efficient.
Material: Premium prefab metal (Q355B Chinese standard or equivalent).
Dimensions: Fully customizable prefab metal parts available in a wide range of sizes to meet project-specific requirements.
Coatings: Available with galvanized, painted, or powder-coated finishes to prevent corrosion and extend service life.
Assembly: Prefabricated for easy on-site assembly, reducing construction time and costs significantly.
Custom Solutions: We provide fully customizable prefab metal designs, ensuring your building meets all your functional and aesthetic needs.
Competitive Pricing: Liyou offers premium prefab metal solutions at competitive prices, ensuring the best value for your project.
Sustainability: Our prefab metal buildings are eco-friendly, offering 100% recyclable materials and a sustainable construction approach.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
