Lower Carbon Footprint:
Liyou Steel Structures is a leading steel building factory that specializes in providing high-quality, durable, and customizable steel structures for a wide range of applications. From industrial warehouses to commercial factories and residential buildings, our steel buildings offer exceptional performance, cost-efficiency, and strength.
Material: High-Quality Galvanized Steel
Design: Custom steel frame construction, with options for clear-span designs to maximize usable space.
Construction Speed: Prefabricated components allow for rapid installation, reducing build time and labor costs.
Energy Efficiency: Insulated panels available to help reduce heating and cooling costs.
Factory-Direct Pricing: As a steel building factory, Liyou offers competitive pricing by cutting out the middleman, allowing you to save on overall project costs.
Proven Durability: Our steel buildings are constructed from high-quality galvanized steel, ensuring long-term performance and resilience against extreme weather conditions.
Global Reach: With projects in countries across the world, Liyou has extensive experience in delivering steel building solutions to diverse industries and regions.
Comprehensive Support: From initial design to final installation, Liyou provides full-service support, ensuring that your steel building project is completed on time, within budget, and to your satisfaction.
| Availability: | |
|---|---|
| Quantity: | |
1. Anchor Bolt and Fastener Part
| No. | Item | Specification |
| 1 | Anchor bolt 1 | M20×400 |
| 2 | Anchor bolt 2 | M16×260 |
| 3 | High-strength bolt | M20, M16, 8.8S |
| 4 | Common bolt | M16 |
| 5 | Galvanized bolt | M12 |
| 6 | Turnbuckle bolt | M16 |
| 7 | Sag rod | Ø12 |
2. Main Steel Structure Part
| No. | Item | Specification |
| 1 | Steel column (Q235B) | HN396×200×7×11 |
| 2 | Wind column (Q235B) | SHS150×100×5.0 |
| 3 | Roof truss beam (Q235B) | HN396×200×7×11 |
| 4 | Floor main beam (Q235B) | HN600×200×11×17 |
| 5 | Tie bar (Q235B) | SHS100×100×5.0 |
| 6 | Horizontal/Column brace (Q235B) | Ø16 |
| 7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
| 8 | Angle brace (Q235B) | L50×6.0 |
| 9 | Roof purlin (Q355B) | C250×75×20×2.0 |
| 10 | Wall purlin (Q355B) | C250×75×20×2.0 |
| 11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
| No. | Item | Specification |
| 1 | Roof plate | 0.6mm thick, type 840 steel sheet |
| 2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
| 3 | Steel man door | 910×2010×2 |
| 4 | Stainless steel handrail | 1.1m high |
| 5 | Roof ventilator | 600×600 |
| 6 | Gutter | 2.0mm galvanized |
| 7 | Downpipe | Ø110 PVC |
| 8 | Trimming | 0.55mm thick steel plate |
| 9 | Hardware accessories | Nails, supports, structural glue, etc. |
