Lower Carbon Footprint:
Liyou's steel carports and garages are a reliable solution for protecting vehicles, machinery, and equipment from the elements. Designed with weather-resistant steel frames and customizable layouts, our carports and garages offer both open-air coverage and fully enclosed protection.
Frame System: Galvanized or painted steel columns and trusses, rigid frame or lightweight tube framing depending on size and application.
Roof Types: Gable, single-slope, or curved roof options, metal sheeting or insulated panels for enhanced protection.
Wall Options: Fully open sides, partial side panels, or full metal walls with doors.
Surface Treatment: Powder coating or hot-dip galvanizing for long-term corrosion resistance.
Tailored to Your Needs: Every unit is designed with your location, usage, and size requirements in mind.
Quick Turnaround: Prefab kits reduce lead time and installation effort.
Global Quality: Proven performance in diverse climates across 15+ countries.
Low Maintenance: Durable materials that require minimal upkeep.
End-to-End Support: Professional guidance from design through delivery.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
