Lower Carbon Footprint:
Liyou's steel structure manufacturing factory solutions are engineered to meet the high-performance standards of modern production facilities. Our factories are built with high-strength steel framing, prefabricated components, and customizable layouts to streamline manufacturing operations across various industries.
Industrial-Grade Steel Framing: Constructed from Q355B steel for superior load-bearing capacity and long-term reliability.
Tailored Layouts: Fully adjustable in dimensions, zoning, access points, and interior clearances to suit production flow.
Energy & Workflow Optimization: Optional skylights, thermal insulation, and ventilation systems to improve comfort and energy use.
Global Adaptability: Engineered to meet international building codes and local environmental loads (snow, wind, seismic).
Integrated Engineering & Fabrication: We manage the full cycle—from structural design to export-ready steel components.
Shorter Build Times: Rapid prefabrication and simplified on-site assembly reduce downtime and speed up ROI.
Certified & Compliant: All structures meet or exceed global standards (CE, ISO, AWS, etc.).
Built for the Future: Structures designed to support automation, smart warehousing, and sustainable operation goals.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
