Steel structure sheds are arguably the most popular type of steel structure prefabricated metal buildings. They are used heavily in commercial and industrial settings, but are also commonly found at construction sites, farms, and even in residential areas.
Steel structures have many benefits over other materials for constructing a building: they're easier to work with than wood or brick; they're less expensive than concrete; and they require substantially less labor to assemble or install. What's more, steel structures can be adjusted to suit almost any design you can imagine. Plus, if you live in a region that experiences hurricanes or earthquakes, chances are a steel structure is the safest option for you.
This is perhaps the most common use of steel structure sheds. You'll find them at retail stores, restaurants, gas stations, car dealerships, and even government offices. Steel structures are easy to outfit to whatever specifications the business owner demands, and they're especially well-suited to high-traffic settings with lots of equipment that has to be kept outside.
You'll most often see steel structures used for manufacturing warehouses. Because these buildings are built for heavy loads, you'll rarely find this type of structure anywhere but an industrial setting.
When you need a steel structure shed to protect your farmland from the elements, you'll find this type of building very common. The main advantage of using a steel structure here is that it needs to be easy to disassemble and rebuild if it experiences any damage.
Steel is extremely durable and sturdy. When you're building something in a high-traffic area or in an area that's prone to natural disasters, it makes sense to use a material that will stand up to the abuse. These buildings are unaffected by any type of weather and take quite the beating before showing any signs of deterioration.
Steel structures are completely recyclable, so you don't have to worry about creating more waste by using them. Also, because of the versatility of steel, once it's been built you can dismantle the parts and reuse them for another building since steel is so easy to work with. This cuts down on a lot of waste and makes for a more environmentally friendly building.
Pre-engineered steel buildings are less expensive than concrete buildings, but they're still not cheap enough that anyone can afford them! The cost effectiveness lies in the fact that they can be erected quickly and with very little labor. At the same time, the steel they're made of is durable enough that you don't have to worry about needing frequent repairs-and more repairs means higher costs!
You can build a structure with less material than a concrete building, which means you pay less for materials. Maybe when it's first being constructed it seems as if there's not much cost savings, but steel buildings are extremely durable, so there are fewer repairs and replacements over time. This saves time and money in the long run!
Area: 520 square meters Weight:50 tons
Wind resistance: 120km/h. Anti-seismic: 8 grade
Roof dead load: 25kg/㎡ Roof live load: 40kg/㎡
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Steel Canopy |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube, steel bar etc. | |
Standard: | Type: |
GB | Light Steel Structure Frame |
Project Size: | Color: |
18.6mx9mx7.25m( can be customized) | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Technology: |
Aluminum plate, Steel Sheet | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | prefabricated steel structure canopy |
Components | Specification |
Embedded parts | |
Embedded parts | M20 |
High strength bolt | M20 |
shear stud | M16*120 |
Main steel frame | |
Steel column(Q235B) | ∅500*20 |
Roof truss beam(Q235B) | HM450X300X11X18、HN400X200X8X13、 口100*80*5.0 |
Customized section steel beam | 12mm steel plate |
Matainence | |
Roof panel | Aluminum plate |
Decorative steel plate | 10mm、5mm steel plate |
Hardware Accessories | Brackets, self-tapping screws, glass glue, etc. |
Horizontal brace | ∅20 |
Connecting plate(Q235B) | 6mm-20mm |
Angle brace(Q235B) | L50*4.0 |
Roof purlin | C180X60X20X2.0 |
Wall purlin | C180X60X20X2.0 |
● Low maintenance costs
● Environmentally friendly and recycling.
● Offer flexibility for fixing doors, windows and interior partitions
● Steel structure construction is strong, durable, and stable.
● Steel components is resistant to termites and other destructive insects.
● The service life of steel structure building is more than 50 years.
● Fast construction, easy installation, and convenient to transport.
Steel structure is widely use as Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Airplane Hangar, Outdoor Stadium Shed, School, Exhibition Hall, Logistics Park, Refrigeration House, Dormitory Building, Shopping Mall etc..
Guangdong LiYou Steel Structure Engineering Co., Ltd. is headquartered in the National High-tech Development Zone, Shishan Town, Nanhai District, Foshan City, and the factory is located in Baini Town, Sanshui District, Foshan City. The head office was established on September 28, 2014. It is a service enterprise integrating steel structure consulting, design, production, construction, and maintenance. Mainly engaged in steel structure prefabricated buildings, including portal steel frames, pipe trusses, box columns/beams, steel lattice columns, H-shaped steel, and other steel structure products.
01 Customized Design
Offer professional building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
Q: What should you provide before quotation?
A: Please send your design drawings, or sketches to us and tell us the materials you want to use. If you do not have the drawings, just inform us more data about the steel building you need, like the building total area, detail dimension, floor amount, roof load, wind load, etc.from all of your requests. If you can make a hand draft, that would be great helpful for us to get your idea.
Q: What accessories do we provide for customized steel buildings?
A: Along with the wall and roof insulation systems, we also offer skylights, commercial-grade ventilation devices such as roof turbine vents and wall louver vents, rolling door, and double sliding doors.
Q: Can the steel building be installed by yourself?
A: Certainly you can. The construction is a simple bolt-together process, which is easy if you have the needed access equipment. Every steel building we make comes with bolts, screws, downspout, gutters, flashing and clear instructions as to show you where everything is to be installed. And we will provide the installation drawing to you for reference.
Q: What should be prepared for the site before installation?
A: You will need concrete piers for the columns to sit upon. Most people pour a full foundation, but if your steel building is on a farm or ranch and there will be dirt, gravel, or sawdust on floors, a pier system may be preferable. In these situations, the popular option is to combine piers with a concrete footing around the perimeter of the building.
Q: Do we have a recommended foundation and associated drawing?
A: Yes, we will provide the foundation drawing and the installation drawing for you after shipment. But the foundation drawing is just for reference because the land and the soil are different in different countries.
