LiYou Steel delivers superior steel structure buildings engineered for maximum strength, durability, and construction efficiency. Our prefabricated industrial buildings are the ideal choice for workshops, manufacturing plants, and storage warehouses requiring reliable, long-lasting structures.
✅ Unmatched Structural Performance
Q355B/Q460C high-tensile steel framing
Clear spans up to 100m (column-free interiors)
Heavy load capacity (up to 20kN/m²)
150km/h wind resistance engineering
✅ Industrial-Grade Durability
✔ Hot-dip galvanized (86µm zinc coating)
✔ Fire-resistant options (up to 120-minute rating)
✔ Corrosion-proof for harsh environments
✔ 50+ year design life
✅ Fast-Track Construction
60% faster completion vs concrete alternatives
Precision prefabricated components (±2mm tolerance)
Bolt-together system minimizes on-site work
All-weather assembly capability
| Component | Specification |
|---|---|
| Primary Frame | Welded steel box sections |
| Secondary Members | Cold-formed Z/C purlins |
| Roof System | Standing seam or trapezoidal |
| Wall Cladding | Single skin or insulated panels |
| Design Standard | GB 50017, AISC, Eurocode |
Manufacturing Plants
Crane systems up to 50T
Vibration-dampening design
Utility distribution channels
Warehousing Facilities
High-bay storage systems
Cross-docking configurations
Automated retrieval compatible
Workshop Buildings
Natural lighting options
Ventilation systems
Flexible floor plans
Cold Storage
-30°C capable insulation
Thermal break construction
Sanitary interior surfaces
Location: Thailand Industrial Park
Size: 120m×80m×12m
Features:
60m clear span
15T overhead cranes
PIR insulated panels
LED lighting system
Construction Time: 20 weeks
✔ 25+ years industrial construction experience
✔ EN 1090/ISO 9001 certified manufacturing
✔ Custom engineering for local codes
✔ Global project management support
✔ Competitive pricing with quality assurance
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Steel Frame House |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube etc. | |
Standard: | Type: |
GB | Steel Structure Frame |
Size: | Color: |
Up to Customer's Requirement | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Insulation: |
Sandwich Panel | EPS, Rockwool, Glass wool, PU etc.. |
Door & Windows: | Technology: |
Steel Door, Aluminum Sliding Window, PVC Window | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Big Metal Building Homes |
Components | Specification |
Anchor Bolt | M30 |
High Strength Bolt | M20，10.9S |
Common Bolt | M16 |
Galvanized Bolt | M12 |
Shear Nail | M16 |
Steel Column(Q345B) | HN600X200X10X15 |
Steel Column(Q345B) | HN300X150X6.5X9 |
Roof Column(Q345B) | HN350X175X6X9 |
Floor Main Beam(Q345B) | HN500X200X9X14 |
Floor Second Beam(Q345B) | HN350X175X6X9 |
Stair | ∅16-bar+2.5mm Chequered Plate |
Tie Rod | ∅89*3.0 |
Horizontal Support | ∅16 |
Roof Purlin（Galvanized) | C180*60*20*2.0 |
Wall Purlin（Galvanized) | C180*60*20*2.0 |
Connecting Plate | 6mm～20mm Steel Sheet |
Paint | 2 Times Spray Paint |
Roof Tile- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
FRP Skylight Panel | Fiber Glass Reinforced Polyester |
Outside Wall Panel -- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
Floor Decking | 1.5mm Galvanized Steel Sheet |
Stair Handrail | 口80*40+口40+口30+口20 |
Gutter | 2.0mm Galvanized Gutter |
Down Pipe | ∅110PVC |
Trimming | 1.0mm Galvanized Steel Sheet |
Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Residential House, Airplane Hangar, Outdoor Stadium Shed, Labour Camp, School, Exhibition Hall, Logistics Park, Refrigeration House, Resort, Dormitory Building, Shopping Mall
01 Customized Design
Offer professional building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
