When your project demands strong structural steel, LiYou Steel Structure Engineering Co., Ltd. delivers high-tensile, load-bearing solutions engineered for maximum stability and longevity. As an industry leader with CE, ISO, and SGS certifications, we provide heavy-duty structural steel components for industrial plants, high-rises, bridges, and mega-infrastructure projects worldwide.
✅ Exceptional Load-Bearing Capacity
Our strong structural steel is manufactured from high-grade Q355B/Q460B alloy, supporting heavy dynamic loads in:
Multi-story industrial facilities (e.g., Andritz Plant, 3,960-ton steel frame)
Long-span structures (e.g., Xiamen Metro maintenance depot, 2,360-ton roof system)
Seismic-resistant buildings (designed to GB 50011-2010 anti-earthquake standards)
✅ Precision Fabrication with Advanced Tech
CNC cutting (±1mm accuracy) and automatic submerged arc welding (SAW) for flawless joints
3D modeling (Tekla Structures) and FEA analysis to optimize stress distribution
✅ Corrosion & Fire Protection
Hot-dip galvanizing (up to 86μm coating) or intumescent paint (120min fire rating)
Complies with ISO 12944 anti-corrosion standards for harsh environments
✅ Proven Global Track Record
2360-ton steel framework for Foshan Metro Line 3 (35,770㎡)
970-ton workshop in Madagascar with 50m clear spans
Heavy Industrial – Power plants, oil & gas facilities
Large-Span Infrastructure – Airport terminals, stadiums
High-Rise Cores – Shear walls, transfer trusses (up to 300m buildings)
Material Traceability: Mill test certificates for all plates/beams
NDT Testing: 100% ultrasonic weld inspection
Load Testing: Prototype validation at 150% design capacity
Availability: | |
---|---|
Quantity: | |
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-096
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
No | Components | Specification | ||
Embedded Parts | ||||
1 | Anchor Bolt | M24 | ||
2 | High Strength Bolt | M20,10.9S | ||
3 | Common Bolt | M16 | ||
4 | Galvanized Bolt | M12 | ||
5 | Shear Nail | M16 | ||
6 | Tir rod | ∅32*2.5 | ||
Main Steel Structure Parts | ||||
1 | Steel Column (Q355B) | H550*300*10*16 | ||
2 | Wind Column (Q355B) | H400*220*6*10 | ||
3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
5 | Tie Bar(Q235B) | ∅168*4.0 | ||
6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
7 | Column Brace (Q235B) | ∅25 | ||
8 | Angle Brace (Q235B) | L63*5.0 | ||
9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
11 | Connecting Plate | 6mm-30mm | ||
Other Steel Structure Parts | ||||
1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
3 | Gutter | 2mm Galvanized Steel Plate | ||
4 | Down Pipe | PVC160 (Including parts) | ||
5 | Trimming | Color steel 0.5mm Gavanized steel panel |
No | Components | Specification | ||
Embedded Parts | ||||
1 | Anchor Bolt | M24 | ||
2 | High Strength Bolt | M20,10.9S | ||
3 | Common Bolt | M16 | ||
4 | Galvanized Bolt | M12 | ||
5 | Shear Nail | M16 | ||
6 | Tir rod | ∅32*2.5 | ||
Main Steel Structure Parts | ||||
1 | Steel Column (Q355B) | H550*300*10*16 | ||
2 | Wind Column (Q355B) | H400*220*6*10 | ||
3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
5 | Tie Bar(Q235B) | ∅168*4.0 | ||
6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
7 | Column Brace (Q235B) | ∅25 | ||
8 | Angle Brace (Q235B) | L63*5.0 | ||
9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
11 | Connecting Plate | 6mm-30mm | ||
Other Steel Structure Parts | ||||
1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
3 | Gutter | 2mm Galvanized Steel Plate | ||
4 | Down Pipe | PVC160 (Including parts) | ||
5 | Trimming | Color steel 0.5mm Gavanized steel panel |
