Availability: | |
---|---|
Quantity: | |
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
Steel Workshop, garage shed, storage closet, buildings prefab workshop, steel warehouse, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard, Other, Kitchen, Bathroom, Home Office, Living Room, Bedroom, Dining, Babies and kids, Outdoor, Storage & Closet, Exterior, Wine Cellar, Entry, Hall, Home Bar, Staircase, Basement, Garage & Shed, Gym, Laundry
Modern
Guangdong, China
Lifetime
engineer guidance
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
1. Hot-Rolled Steel Sections
(Primary Framework)
H-Beams (GB/T 11263-2017)
Size: 300×300×10×15mm
Grade: Q355B
Application: Main columns in fabrication bay
I-Beams (ASTM A6)
Size: 24"×12"
Grade: A572 Gr.50
Application: Crane runway beams
2. Cold-Formed Sections
(Secondary Structure)
C-Purlins
Thickness: 2.0-3.0mm
Coating: G550 AZ150
Spacing: 1.5m on-center
Sigma Profiles
Special shape for roof bracing
Custom roll-formed sections
3. Hollow Structural Sections (HSS)
(Wash Bay & Architectural Features)
Rectangular Hollow (EN 10219-1)
200×100×6mm
316L stainless steel option
Circular Hollow
Φ150×5mm
Hot-dip galvanized
4. Custom Fabricated Sections
Plate Girders
Web: 12mm thick
Flange: 25mm thick
Stiffener spacing: 1.2m
Built-Up Box Sections
For high moment-resisting connections
Section Type | Yield Strength | Typical Use | Cost Efficiency |
---|---|---|---|
Hot-Rolled H | 355MPa | Primary frames | ★★★★ |
Cold-Formed C | 550MPa | Roof/Walls | ★★★★★ |
Hollow Tube | 275-460MPa | Aesthetic/Corrosive areas | ★★★ |
Built-Up | Custom | Heavy loads | ★★ |
Structural Optimization Features:
Service Bay: Lightweight C-sections (30% material savings)
Fabrication Bay: Moment-resisting welded sections (EN 1090 EXC3)
Storage Bay: Economical lattice girders (40% vs solid web)
Wash Bay: 3mm stainless steel cladding over HSS
Certifications Included:
CE Marking (EN 1090)
ISO 3834 Welding Quality
Third-party material test reports
item | value |
Warranty | 3 years |
After-sale Service | Online technical support |
Project Solution Capability | total solution for projects |
Application | Workshop |
Place of Origin | China |
Guangdong | |
Material | Steel |
Use | workshop |
Product Type | Warehouse |
Design Style | Modern |
Certification | CE Certification |
Application Fields | Industrial Commercial |
Purlin | C.Z Shape Steel Channel |
Door | Sliding Door |
Color | Customized Color |
Wall and Roof | Sandwich Panel Optional |
Window | Aluminum Alloy Sliding Window |
Drawing Design | SAP2000/AutoCAD /PKPM /3D3S/TEKLA |
Surface treatment | Hot Dip Galvanized |
Delivery time | 25-60 days |
