✔ Superior Load Capacity - Our hot-rolled structural steel I-beams distribute weight evenly, supporting heavy loads with minimal deflection.
✔ Custom Sizes Available - From lightweight 100×50mm to heavy-duty 900×300mm profiles, we manufacture to your exact specifications.
✔ Material Excellence - Fabricated from high-quality Q235B/Q355B steel with yield strengths up to 355MPa.
✔ Precision Engineering - Laser-cut flanges and web plates ensure perfect dimensional accuracy (±1mm tolerance).
| Quantity: | |
|---|---|
Steel
Online technical support
Steel Agricultural Shed
Guangdong, China
Industrial Area
3 years
total solution for projects
LYB-001
Steel Agricultural Shed
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
When strength and efficiency matter most, structural steel I-beams from Guangdong LiYou Steel Structure Engineering Co., Ltd. deliver unmatched performance. As a leading global manufacturer, we produce premium-grade structural steel I-beams that form the skeletal framework for factories, warehouses, bridges, and high-rise buildings worldwide.
| Parameter | Specification Range |
|---|---|
| Standard Lengths | 6m, 9m, 12m (custom up to 18m) |
| Flange Width | 50mm - 400mm |
| Web Thickness | 3mm - 40mm |
| Surface Treatment | Shot-blasted & primed (optional galvanizing) |
Industrial: Factory support beams, crane runways
Commercial: Mezzanine floors, parking structures
Infrastructure: Bridge girders, railway platforms
Residential: High-rise building frames
Raw Material Inspection - Ultrasonic testing for internal defects
Production Monitoring - Real-time dimension checks during rolling
Final Verification - 3D scanning against CAD models
Case Study: Our 850×300mm structural steel I-beams were used in the Philippine Logistics Warehouse (11,790m²), supporting 25-ton overhead cranes with zero deformation over 5+ years.
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
When strength and efficiency matter most, structural steel I-beams from Guangdong LiYou Steel Structure Engineering Co., Ltd. deliver unmatched performance. As a leading global manufacturer, we produce premium-grade structural steel I-beams that form the skeletal framework for factories, warehouses, bridges, and high-rise buildings worldwide.
| Parameter | Specification Range |
|---|---|
| Standard Lengths | 6m, 9m, 12m (custom up to 18m) |
| Flange Width | 50mm - 400mm |
| Web Thickness | 3mm - 40mm |
| Surface Treatment | Shot-blasted & primed (optional galvanizing) |
Industrial: Factory support beams, crane runways
Commercial: Mezzanine floors, parking structures
Infrastructure: Bridge girders, railway platforms
Residential: High-rise building frames
Raw Material Inspection - Ultrasonic testing for internal defects
Production Monitoring - Real-time dimension checks during rolling
Final Verification - 3D scanning against CAD models
Case Study: Our 850×300mm structural steel I-beams were used in the Philippine Logistics Warehouse (11,790m²), supporting 25-ton overhead cranes with zero deformation over 5+ years.
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
