Lower Carbon Footprint:
Looking for a fast, scalable, and long-lasting storage solution? Liyou offers warehouse steel structures for sale that meet the rigorous demands of industrial operations. With prefabricated components, customizable designs, and a robust steel frame, our warehouse systems are trusted worldwide for strength, speed, and savings.
Frame System: Portal frame using welded or bolted H-section beams.
Steel Type: Q235B / Q355B compliant with international standards.
Roof Design: Gable or mono-slope, optional skylights and ventilators.
Optional Features: Rolling shutter doors, ventilation systems, internal partitions, drainage, solar integration.
Industrial Warehouses: Equipment housing, raw material storage, and machinery workshops.
Commercial Distribution: Stock holding, logistics centers, and fulfillment hubs.
Agricultural Use: Storage for grain, tractors, fertilizer, and livestock feed.
Cold Chain & Packaging: Customization available for refrigerated or temperature-controlled warehousing.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
