Guangdong LiYou Steel Structure Engineering Co., Ltd. +8619147784007 liyousteelstructure@outlook.com
 |
Our Multifunctional Metal Frame Factory is engineered for versatility, durability, and cost-efficiency, making it ideal for industrial, manufacturing, and storage applications. Utilizing high-strength steel structures, these factories offer rapid construction, long-term reliability, and sustainable design—perfect for businesses seeking scalable and adaptable workspaces.
| Quantity: | |
|---|---|
✔ Lightweight Yet Strong
High strength-to-weight ratio enables large-span designs (up to 100m+) without internal columns.
Ideal for heavy machinery, warehouses, and production lines.
✔ Fast Construction & Cost Savings
Prefabricated components reduce build time by 50%+ vs. traditional methods.
Lower labor and material costs with optimized steel usage.
✔ Sustainable & Relocatable
100% recyclable materials with minimal environmental impact.
Easy to dismantle, move, and reuse—ideal for temporary or expanding operations.
✔ Design Flexibility
Customizable layouts for manufacturing plants, logistics hubs, or workshops.
Options for skylights, ventilation systems, and crane beams.
⚠ Considerations:
Fire Resistance: Requires additional coatings/fireproofing for high-risk industries.
Corrosion Protection: Galvanized or painted steel recommended for humid/coastal areas.
| Feature | Advantage |
|---|---|
| Material | High-grade galvanized steel (G550) |
| Span Capacity | Up to 100m+ (column-free) |
| Construction Time | 3-6 months (vs. 12+ months for concrete) |
| Lifespan | 40+ years with proper maintenance |
| Eco-Friendliness | Fully recyclable, low waste |
Manufacturing Plants – Automotive, textiles, machinery
Warehousing – High-bay storage, distribution centers
Aircraft Hangars – Large clear-span requirements
Temporary Factories – Relocatable and expandable
✅ 25+ Years of Expertise in steel structures
✅ Global Certifications (ISO, CE, ASTM)
✅ End-to-End Service – Design, fabrication, installation
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Steel Frame House |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube etc. | |
Standard: | Type: |
GB | Steel Structure Frame |
Size: | Color: |
Up to Customer's Requirement | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Insulation: |
Sandwich Panel | EPS, Rockwool, Glass wool, PU etc.. |
Door & Windows: | Technology: |
Steel Door, Aluminum Sliding Window, PVC Window | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Big Metal Building Homes |
Components | Specification |
Anchor Bolt | M30 |
High Strength Bolt | M20，10.9S |
Common Bolt | M16 |
Galvanized Bolt | M12 |
Shear Nail | M16 |
Steel Column(Q345B) | HN600X200X10X15 |
Steel Column(Q345B) | HN300X150X6.5X9 |
Roof Column(Q345B) | HN350X175X6X9 |
Floor Main Beam(Q345B) | HN500X200X9X14 |
Floor Second Beam(Q345B) | HN350X175X6X9 |
Stair | ∅16-bar+2.5mm Chequered Plate |
Tie Rod | ∅89*3.0 |
Horizontal Support | ∅16 |
Roof Purlin（Galvanized) | C180*60*20*2.0 |
Wall Purlin（Galvanized) | C180*60*20*2.0 |
Connecting Plate | 6mm～20mm Steel Sheet |
Paint | 2 Times Spray Paint |
Roof Tile- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
FRP Skylight Panel | Fiber Glass Reinforced Polyester |
Outside Wall Panel -- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
Floor Decking | 1.5mm Galvanized Steel Sheet |
Stair Handrail | 口80*40+口40+口30+口20 |
Gutter | 2.0mm Galvanized Gutter |
Down Pipe | ∅110PVC |
Trimming | 1.0mm Galvanized Steel Sheet |
Steel Structure Building Applications
Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Residential House, Airplane Hangar, Outdoor Stadium Shed, Labour Camp, School, Exhibition Hall, Logistics Park, Refrigeration House, Resort, Dormitory Building, Shopping Mall.
01 Customized Design
Offer professional building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
