Lower Carbon Footprint:
Liyou offers high-performance galvanized steel structures engineered to withstand harsh environments and corrosive conditions. Our structures are pre-treated with zinc coatings to ensure long-term durability, making them ideal for projects that demand strength and minimal maintenance.
Material Quality: Fabricated from robust steel materials treated with protective coatings.
Coating Method: Surface protected through industrial-grade galvanization for enhanced longevity.
Structural System: Includes primary load-bearing frames, secondary supports, and necessary reinforcements.
Connection Design: Assembled with precision-engineered fasteners or welded joins, depending on project requirements.
Environmental Performance: Designed for resilience in corrosive, humid, or high-wear conditions.
Global Trust, Local Expertise: Backed by international success, we bring tailored expertise to every project.
Built for the Long Haul: Our galvanization process ensures structural integrity and long-term visual appeal.
Flexible, Scalable Designs: Adaptable for small-scale farms or expansive industrial developments.
Streamlined Export & Delivery: We handle everything from engineering to global shipment with precision and speed.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
