Lower Carbon Footprint:
Liyou offers high-quality metal building frame kits that are designed to provide a solid and reliable foundation for any construction project. Whether you are building a residential garage, a commercial warehouse, or an industrial factory, our customizable steel frame kits ensure durability, strength, and fast installation.
Material: High-quality galvanized steel or cold-rolled steel for exceptional durability and weather resistance.
Dimensions: Customizable widths, heights, and lengths to fit a variety of building requirements.
Roof Style: Available in several roof designs, including gable, single-slope, and custom profiles.
Ease of Assembly: Modular design for easy on-site assembly with clear instructions, reducing construction time and labor costs.
Insulation Options: Available insulation options to improve energy efficiency and provide temperature control for your building.
Residential: Garages, workshops, and storage sheds.
Commercial: Retail stores, office spaces, and exhibition halls.
Industrial: Warehouses, manufacturing plants, and equipment storage.
Agricultural: Barns, livestock shelters, and storage for farming equipment.
Recreational: Sports halls, gyms, and hobby workshops.
Public Infrastructure: Schools, community centers, and recreational facilities.
Availability: | |
---|---|
Quantity: | |
1. Anchor Bolt and Fastener Part
No. | Item | Specification |
1 | Anchor bolt 1 | M20×400 |
2 | Anchor bolt 2 | M16×260 |
3 | High-strength bolt | M20, M16, 8.8S |
4 | Common bolt | M16 |
5 | Galvanized bolt | M12 |
6 | Turnbuckle bolt | M16 |
7 | Sag rod | Ø12 |
2. Main Steel Structure Part
No. | Item | Specification |
1 | Steel column (Q235B) | HN396×200×7×11 |
2 | Wind column (Q235B) | SHS150×100×5.0 |
3 | Roof truss beam (Q235B) | HN396×200×7×11 |
4 | Floor main beam (Q235B) | HN600×200×11×17 |
5 | Tie bar (Q235B) | SHS100×100×5.0 |
6 | Horizontal/Column brace (Q235B) | Ø16 |
7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
8 | Angle brace (Q235B) | L50×6.0 |
9 | Roof purlin (Q355B) | C250×75×20×2.0 |
10 | Wall purlin (Q355B) | C250×75×20×2.0 |
11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
No. | Item | Specification |
1 | Roof plate | 0.6mm thick, type 840 steel sheet |
2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
3 | Steel man door | 910×2010×2 |
4 | Stainless steel handrail | 1.1m high |
5 | Roof ventilator | 600×600 |
6 | Gutter | 2.0mm galvanized |
7 | Downpipe | Ø110 PVC |
8 | Trimming | 0.55mm thick steel plate |
9 | Hardware accessories | Nails, supports, structural glue, etc. |
