Metal Building Frame

Liyou specializes in providing metal building frames designed to support a wide range of construction projects, from residential homes to large commercial and industrial structures. With years of experience and a global presence, Liyou is your trusted partner for high-quality, cost-effective steel building frames.



Technical Specifications

Material: High-quality galvanized steel or cold-rolled steel for strength and corrosion resistance.

Dimensions: Custom sizes to fit the specific requirements of your project, from small residential buildings to large industrial complexes.

Design Flexibility: Available in various frame styles, including clear-span frames for open spaces and traditional framed structures with columns and beams.

Assembly: Pre-engineered for easy and quick on-site assembly, reducing labor costs and construction time.



Availability:
Quantity:
Inquire





What Is Included in a Metal Building Frame


A standard metal building frame typically includes:

·  Steel columns and main beams

·  Roof rafters or rigid frames

·  Bracing systems for stability

·  Connection plates and anchor components

The frame is engineered based on building size, span, and load requirements.





Applications of Metal Building Frames


Metal building frames are commonly used for:

·  Warehouses and storage buildings

·  Workshops and manufacturing facilities

·  Carports and utility shelters

·  Agricultural buildings and barns

·  Commercial and industrial structures

They are suitable for projects that require open interior space and strong structural support.





Types of Metal Building Frames


Depending on project requirements, metal building frames can be designed as:

Single-span or multi-span frames

Rigid frame systems

Portal frame structures

Multi-bay structural frames

Each type is selected based on span length, load conditions, and building function.





Metal Building Frame Advantages


·  High load-bearing capacity

·  Flexible design for different building sizes

·  Long service life with proper surface treatment

·  Compatible with various roofing and wall systems

·  Suitable for prefabrication and fast installation

These advantages make metal building frames a reliable foundation for steel buildings.




Project Specifications
Dimensions: 31m (L) × 14m (W) × 6.5m (H)

Steel Material: GB Q235B / Q355B

Design: Fully Customized

Required Containers: 2–3 x 40HC

Delivery Time: 20–30 Days

Shipping Time: ~20 Days

Installation Time: 10 Days





Galvanized Steel Advantages

Corrosion Resistance
Zinc Coating Protection:
Acts as a sacrificial layer to prevent rust.

Extended Lifespan:
Reduces maintenance frequency.

Weather Durability:
Performs well in moisture- and salt-prone environments.
Sustainability
Eco-Friendly:
100% recyclable.

Lower Carbon Footprint:
Long service life means fewer replacements.




Aesthetic Appeal
Modern Appearance:
Clean, sleek look.

Custom Finishes Available:
Adaptable to various architectural styles.







Key Features
1
Precision-Engineered Steel Columns & Beams
Every structural component is labeled with a unique identifier for easy on-site identification and smooth assembly.
2
Tailor-Made Solutions
Designed to match your specific requirements for layout, function, and aesthetics.
3
Fast and Efficient Installation
Optimized for quick on-site assembly with clearly marked parts.
4
Cost-Effective & Low Maintenance
Built to last with minimal upkeep, reducing long-term costs.



1
Warranty Information

Applicable Products：Steel Structure Warehouses, Workshops, Multi-Story Buildings

I-Beam Structural Warranty: 50 Years
Galvalume Roof Warranty: 25 Years
Standing Seam Roof Warranty: 20 Years
Read More



Why Choose Liyou Steel Structure
At Liyou, every project begins with clear communication and collaboration. We take time to understand how your structure will be used, where it will be located, and your preferences for design—inside and out.

Our engineers also consider environmental factors like wind and snow loads, along with insulation needs, to ensure your hangar is safe, compliant, and durable. Once your ideal building kit is identified, we help customize it with doors, windows, and color options—flexibly and cost-effectively.

From concept to completion, we deliver quality materials, thoughtful design, and professional support to bring your vision to life.
Read More


Loading and Shipping


1. Anchor Bolt and Fastener Part


No.ItemSpecification
1Anchor bolt 1M20×400
2Anchor bolt 2M16×260
3High-strength boltM20, M16, 8.8S
4Common boltM16
5Galvanized boltM12
6Turnbuckle boltM16
7Sag rodØ12



2. Main Steel Structure Part


No.ItemSpecification
1Steel column (Q235B)HN396×200×7×11
2Wind column (Q235B)SHS150×100×5.0
3Roof truss beam (Q235B)HN396×200×7×11
4Floor main beam (Q235B)HN600×200×11×17
5Tie bar (Q235B)SHS100×100×5.0
6Horizontal/Column brace (Q235B)Ø16
7Steel stairs[250#、[200#、[160# channel steel, 4mm checkered plate]
8Angle brace (Q235B)L50×6.0
9Roof purlin (Q355B)C250×75×20×2.0
10Wall purlin (Q355B)C250×75×20×2.0
11Connecting plate (Q235B)6mm–16mm



3. Enclosure Part


No.ItemSpecification
1Roof plate0.6mm thick, type 840 steel sheet
2Exterior wall0.6mm thick, type 900 steel sheet
3Steel man door910×2010×2
4Stainless steel handrail1.1m high
5Roof ventilator600×600
6Gutter2.0mm galvanized
7DownpipeØ110 PVC
8Trimming0.55mm thick steel plate
9Hardware accessoriesNails, supports, structural glue, etc.
