Metal building is known as a type of building constructed with structural elements such as girders, columns and beams made exclusively from structural steel, which makes it the strongest type of construction. It is said that constructing strong buildings out of metal will change the face of engineering.
Metal building is said to be more fire and seismic resistant as compared to other types of buildings. This means that metal building is also earthquake resistant.
Metal building's design can be modified and changed depending on the project requirements, because metal building's design is not restricted by any conventional building techniques. Metal Building allows a lot of styling techniques, with unlimited possibilities in the choice of finishes.
Metal buildings are known to require less energy and less maintenance cost. This is because metal buildings are not at all vulnerable to termite, rot and fire. The metal building can last up to 500 years if well taken care of by its owner. Other types of buildings need regular repainting, re-roofing and other forms of maintenance over a long period of time, which is expensive and time consuming. Metal building also improve the value of one's property as it increases curb appeal by adding value to the home or business it resides in.
With metal building, it is possible to create a large space without the interference of columns or walls. Metal Building can be carried out without a lot of interference from columns or walls. This simply means that a lot of usable space can be created inside and outside the structure.
Metal building is said to be durable as compared to other types of buildings. A well-established and well-maintained iron building can last up to 500 years, which is much more than other conventional buildings that can only last around 100 years before they need repairs. The metal building is not at all sensitive to weather conditions and it is also not vulnerable to fire, earthquake or termite.
Metal building is said to be a type of environmentally friendly building as there are no emissions from the structure, making it very desirable because it does not require any energy for adequate ventilation or for heat. The metal building can be used during the entire year and it can be used as a greenhouse in the summer and as a steel-reinforced warehouse during winter.
With the development of global technology and industrialization, there is hardly any new construction technique that has not been tested. Metal building is an example of the new construction techniques that have already been tested and found to be very stable, reliable and strong. Its durability, strength and resistance to fire and seismic means that metal building will continue to become a major source of construction in the future.
The ability to create long clear spans and its speed of construction are some of the reasons why steelwork is the ideal framing solution for car factories and showrooms.
The Project Aera: 5500㎡ Weight: 200 tons
Wind Resistance: 110km/h Anti Seismic: 8 grade
Floor Dead load: 35kg/㎡ Floor Live Load:50kg/㎡
Place of Origin: | Product Portal Frame: |
Foshan, China (Mainland) | Steel Construction Frame Building |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube etc. | |
Standard: | Type: |
GB | Light Steel Structure Frame |
Size: | Color: |
Up to Customer's Requirement | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Door: |
Sandwich Panel: 50mm, 0.376 Steel sheet | Rolling Door |
Window: | Technology: |
Aluminum Alloy Window | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Metal buildings for sale |
| Components | Specification |
| Embedded parts | |
| Anchor bolt | M24 |
| High strength bolt | M20，10.9S |
| Common bolt | M20 |
| Galvanized bolts | M12 |
| Bracing | M12 |
| Main steel frame | |
| Steel column（Q235B） | HN346*174*6*9 |
| Wind column（Q235B） | HN298*149*5.5*8 |
| Roof truss（Q235B） | HN(580-298)*149*5.5*8 |
| Tie rod | ∅89*3.0 |
| Horizontal brace | ∅20 steel bar |
| Column brace | ∅20 steel bar |
| Roof purlin(Galvanized) | C160*50*20*2.0 |
| Wall purlin(Galvanized) | C160*50*20*2.0 |
| Connecting plate | 6~20mm steel sheet |
| Structure steel fabrication+Sanding + Paint | Acetylene, oxygen, electrode, Sa2.5 |
| Maintenance | |
Roof panel | 50mm |
Outside wall panel | 100mm |
| Trimming | Galvanized plate,steel sheet |
| Door&Window | |
| Aluminum glass door(double open) | W1800*H2400 |
Aluminium slidding window | W1740*H1500 |
Ceiling | 600*600 |
| Gutter | 2.0mm Galvanized |
| Down pie | PVC material |
● Low maintenance costs
● Environmentally friendly and recycling.
● Offer flexibility for fixing doors, windows and interior partitions
● Steel structure construction is strong, durable, and stable.
● Steel components are resistant to termites and other destructive insects.
● The service life of steel structure building is more than 50 years.
● Fast construction, easy installation, and convenient to transport.
The steel structure is a light steel structure product, the main structure is cold-formed thin-wall steel component by bolt connection, it could be also combined with another unit by span each other, to ahieve more than span sapce. Comparing with the traditional steel structure, it owns simple architecture, low cost material, small dimension transport, steel structure life span can be up to 50 yearts, it can be used repeatedly.
The steel structure building is widely used in the construction of buildings such as Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Residential House, Airplane Hangar, Outdoor Stadium Shed, Labour Camp, School, Exhibition Hall, Logistics Park, Refrigeration House, Resort, Dormitory Building, Shopping Mall, etc.
Guangdong LiYou Steel Structure Engineering Co., Ltd. is headquartered in the National High-tech Development Zone, Shishan Town, Nanhai District, Foshan City, and the factory is located in Baini Town, Sanshui District, Foshan City. The head office was established on September 28, 2014. It is a service enterprise integrating steel structure consulting, design, production, construction, and maintenance. Mainly engaged in steel structure prefabricated buildings, including portal steel frames, pipe trusses, box columns/beams, steel lattice columns, H-shaped steel, and other steel structure products.
01 Customized Design
Offer professional Steel Structure Portal Frames building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
Q: What should you provide before quotation?
A: Please send your design drawings, or sketches to us and tell us the materials you want to use. If you do not have the drawings, just inform us more data about the steel building you need, like the building total area, detail dimension, floor amount, roof load, wind load, etc.from all of your requests. If you can make a hand draft, that would be great helpful for us to get your idea.
Q: What accessories do we provide for customized steel buildings?
A: Along with the wall and roof insulation systems, we also offer skylights, commercial-grade ventilation devices such as roof turbine vents and wall louver vents, rolling door, and double sliding doors.
Q: Can the steel building be installed by yourself?
A: Certainly you can. The construction is a simple bolt-together process, which is easy if you have the needed access equipment. Every steel building we make comes with bolts, screws, downspout, gutters, flashing and clear instructions as to show you where everything is to be installed. And we will provide the installation drawing to you for reference.
Q: What should be prepared for the site before installation?
A: You will need concrete piers for the columns to sit upon. Most people pour a full foundation, but if your steel building is on a farm or ranch and there will be dirt, gravel, or sawdust on floors, a pier system may be preferable. In these situations, the popular option is to combine piers with a concrete footing around the perimeter of the building.
Q: Do we have a recommended foundation and associated drawing?
A: Yes, we will provide the foundation drawing and the installation drawing for you after shipment. But the foundation drawing is just for reference because the land and the soil are different in different countries.
