Lower Carbon Footprint:
Need a fast, scalable, and reliable structure? Liyou's Prefab Metal Building solutions offer unmatched speed, strength, and design flexibility. Built to perform in diverse environments, our steel systems are pre-engineered to accelerate timelines, reduce labor, and adapt effortlessly to your project's exact needs.
Commercial showrooms and supermarkets
Storage warehouses and logistic parks
Industrial production halls
Agricultural buildings and livestock shelters
Government infrastructure and disaster relief shelters
Turnkey Capability: From design to on-site guidance, we manage the full lifecycle.
High Precision Production: CNC cutting, automated welding, and robot-assisted assembly.
Fast Global Shipping: Optimized packaging and overseas logistics streamline delivery.
Flexible Design Options: Fully customizable exterior and interior building specs.
Proven Quality Control: ISO 9001-certified processes and strict in-factory inspection.
| Availability: | |
|---|---|
| Quantity: | |
1. Anchor Bolt and Fastener Part
| No. | Item | Specification |
| 1 | Anchor bolt 1 | M20×400 |
| 2 | Anchor bolt 2 | M16×260 |
| 3 | High-strength bolt | M20, M16, 8.8S |
| 4 | Common bolt | M16 |
| 5 | Galvanized bolt | M12 |
| 6 | Turnbuckle bolt | M16 |
| 7 | Sag rod | Ø12 |
2. Main Steel Structure Part
| No. | Item | Specification |
| 1 | Steel column (Q235B) | HN396×200×7×11 |
| 2 | Wind column (Q235B) | SHS150×100×5.0 |
| 3 | Roof truss beam (Q235B) | HN396×200×7×11 |
| 4 | Floor main beam (Q235B) | HN600×200×11×17 |
| 5 | Tie bar (Q235B) | SHS100×100×5.0 |
| 6 | Horizontal/Column brace (Q235B) | Ø16 |
| 7 | Steel stairs | [250#、[200#、[160# channel steel, 4mm checkered plate] |
| 8 | Angle brace (Q235B) | L50×6.0 |
| 9 | Roof purlin (Q355B) | C250×75×20×2.0 |
| 10 | Wall purlin (Q355B) | C250×75×20×2.0 |
| 11 | Connecting plate (Q235B) | 6mm–16mm |
3. Enclosure Part
| No. | Item | Specification |
| 1 | Roof plate | 0.6mm thick, type 840 steel sheet |
| 2 | Exterior wall | 0.6mm thick, type 900 steel sheet |
| 3 | Steel man door | 910×2010×2 |
| 4 | Stainless steel handrail | 1.1m high |
| 5 | Roof ventilator | 600×600 |
| 6 | Gutter | 2.0mm galvanized |
| 7 | Downpipe | Ø110 PVC |
| 8 | Trimming | 0.55mm thick steel plate |
| 9 | Hardware accessories | Nails, supports, structural glue, etc. |
