As a premier manufacturer of residential steel roof trusses, Liyou Steel provides high-strength, precision-engineered truss systems that outperform traditional wood framing. Our cold-formed steel (CFS) trusses deliver superior span capabilities, straightness, and longevity for modern homes.
✔ Unmatched Structural Performance
Clear spans up to 60 feet without interior supports
2-3x stronger than dimensional lumber
Consistent quality – no warping or shrinking
✔ Superior Material Advantages
Galvanized steel (G550) – rust and termite resistant
30% lighter than wood – reduces foundation loads
Non-combustible (Class A fire rating)
✔ Construction Benefits
50% faster installation vs. stick framing
Pre-engineered components for perfect fit
Compatible with all roofing materials
| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-001
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
A prefabricated steel roof truss is a factory‑fabricated, precision‑engineered structural framework designed to support roof loads in residential and commercial buildings. Compared to traditional wood roof trusses, steel trusses offer higher strength‑to‑weight ratios, consistent structural quality, and superior resistance to termite, fire, and weather effects — making them an ideal choice for modern construction.
A prefabricated steel roof truss consists of interconnected steel members arranged in a triangulated pattern that efficiently distributes loads from the roof surface down to the supporting walls or columns. These trusses are manufactured off‑site and delivered ready for assembly, reducing on‑site work and accelerating construction schedules.
Steel trusses may be made from cold‑form steel (typically G550 light gauge), hot‑rolled members, or hybrid configurations depending on span, load requirements, and architectural design.
Steel trusses outperform wood in strength and lifespan. They can span longer distances without intermediate supports, enabling open interior spaces and flexible designs.
Factory fabrication ensures every truss meets strict tolerances and engineered specifications, reducing variation and potential on‑site errors.
Prefabricated components arrive ready to install, speeding up roof framing and lowering labor costs when compared with traditional stick‑built methods.
Steel does not warp, split, or decay like wood, and it inherently resists termites and moisture‑related damage. With proper coatings (galvanization), steel trusses maintain performance in extreme weather conditions.
Prefabricated steel roof trusses are suitable for:
Single‑Family Homes & Villas — reliable roof framing with long lifespan
Garages & Accessory Buildings — robust support for secondary structures
Modern Architectural Designs — open plans, vaulted ceilings, attic spaces
Remodeling & Renovations — retrofit applications where wood might fail
Steel truss systems support a variety of roofing materials and are compatible with most residential roof designs.
| Truss Type | Best For |
|---|---|
| Fink Truss | Most residential roofs |
| Scissor Truss | Vaulted ceilings, open interiors |
| Attic Truss | Bonus space, storage above |
| Cantilever | Extended overhangs/porches |
We provide prefabricated steel roof trusses with customizable parameters:
Span length and roof pitch
Steel grade and gauge
Connection types (bolted or welded)
Compatibility with insulation and roofing materials
Engineering calculations and stamped drawings for permits
Our team supports you from initial design through fabrication and delivery, ensuring compliance with local building codes.
Submit Architectural Plans – Provide house plans or roof geometry
Engineering & Load Calculations – We engineer for snow, wind, and live loads
Shop Fabrication – Trusses are prefabricated with precision
Delivery & On‑Site Assembly – Labeled components for fast installation
Inspection & Warranty Support – Quality assurance with documentation
Q: Are steel roof trusses better than wood for homes?
Steel trusses offer higher strength, fire resistance, and dimensional stability compared to wood, with fewer issues like warping or pest damage.
Q: Can steel roof trusses be customized?
Yes. They can be engineered for specific spans, roof pitches, and load conditions based on your home design.
Q: Do prefabricated steel trusses cost more than wood?
Steel trusses can have a higher initial material cost but typically reduce long‑term maintenance and labor costs, often proving more economical over the building's lifetime.
PRODUCT SPECIFICATIONS
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
