When it comes to steel shade structure design, Liyou Steel Structure combines innovation, functionality, and aesthetics to deliver high-performance solutions for commercial, industrial, and public spaces. Our steel shade structures are engineered to withstand harsh weather conditions while enhancing visual appeal, making them ideal for parking lots, walkways, stadiums, and outdoor recreational areas.
Commercial: Carports, shopping mall entrances, gas station canopies
Public Infrastructure: Bus stops, pedestrian walkways, park shelters
Industrial: Warehouse loading bays, equipment shading
Recreational: Stadium roofs, poolside covers, outdoor event spaces
| Quantity: | |
|---|---|
Steel
Online technical support
Warehouse
Guangdong, China
Warehouse
3 years
total solution for projects
LYB-001
Warehouse
Industrial
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
Single item
1X1X1 cm
1.000 kg
High Durability: High-strength steel resists corrosion, UV damage, and harsh weather.
Customizable Design: Tailor dimensions, roof style, colors, and finishes.
Wide Applications: Perfect for parking areas, outdoor walkways, recreational spaces, and industrial sites.
Efficient Installation: Prefabricated steel components ensure quick and precise assembly.
Low Maintenance: Minimal upkeep required with long-lasting protective coatings.
Aesthetic Appeal: Modern designs that enhance outdoor space visuals.
| Type | Description | Typical Use |
|---|---|---|
| Cantilever Shade | Supported on one side for unobstructed space | Parking lots, walkways |
| Flat Roof Shade | Simple, functional roof design | Patios, commercial areas |
| Curved / Arched Shade | Elegant curved design | Parks, recreational areas |
| Multi-Bay Shade | Large coverage with multiple connected sections | Industrial sites, large parking areas |
Requirement Analysis: Assess site dimensions, shade area, and load requirements.
Custom Design: Create CAD drawings and 3D renderings of the structure.
Material Selection: Choose steel grade, roof material, and coatings.
Fabrication: Prefabricated components manufactured to exact specifications.
Delivery & Assembly: Steel components delivered and installed with guidance or full installation service.
Inspection & Quality Check: Ensure all bolts, welds, and panels meet safety standards.
Parking Lots & Carports: Protect vehicles from sun, rain, and snow.
Commercial Spaces: Enhance outdoor areas of restaurants, malls, or offices.
Parks & Recreational Areas: Provide shaded spaces for visitors and equipment.
Industrial Facilities: Shelter machinery, materials, or staff areas.
Dimensions & Layout: Single-bay, multi-bay, or customized shapes.
Roof & Finish Options: Galvanized steel, powder-coated, or color-painted steel panels.
Optional Features: Lighting, solar panels, or wind-resistant reinforcements.
Request a Quote: Submit your project specifications for a custom steel shade structure design and pricing.
| No | Components | Specification | ||
| Embedded Parts | ||||
| 1 | Anchor Bolt | M24 | ||
| 2 | High Strength Bolt | M20,10.9S | ||
| 3 | Common Bolt | M16 | ||
| 4 | Galvanized Bolt | M12 | ||
| 5 | Shear Nail | M16 | ||
| 6 | Tir rod | ∅32*2.5 | ||
| Main Steel Structure Parts | ||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||
| 7 | Column Brace (Q235B) | ∅25 | ||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||
| 11 | Connecting Plate | 6mm-30mm | ||
| Other Steel Structure Parts | ||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||
| 4 | Down Pipe | PVC160 (Including parts) | ||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||
