Q: How long does fireproofing last?
A: 15-25 years (SFRM), 20-30 years (intumescent) with proper maintenance.
Q: Can fireproofing be applied outdoors?
A: Yes - Requires weather-resistant topcoat (we recommend polyurethane).
Q: What's the lightest fireproof solution?
A: Thin-film intumescent (1-2mm) for 60-90 minute ratings.
| Quantity: | |
|---|---|
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
garage shed, storage closet, poultry houses, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard, Other, Kitchen, Bathroom, Home Office, Living Room, Bedroom, Dining, Babies and kids, Outdoor, Storage & Closet, Exterior, Wine Cellar, Entry, Hall, Home Bar, Staircase, Basement, Garage & Shed, Gym, Laundry
steel
Guangdong, China
Modern
Lifetime
Liyou
LYB-001
CE Certification
Industrial Commercial
C.Z Shape Steel Channel
Sliding Door
Customized Color
Sandwich Panel Optional
Aluminum Alloy Sliding Window
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Hot Dip Galvanized
25-60 days
| Method | Thickness | Fire Rating | Cost/m² | Best For |
|---|---|---|---|---|
| Spray-Applied (SFRM) | 15-50mm | 30-240 mins | $25-60 | Industrial, high-rise |
| Intumescent Paint | 0.5-5mm | 30-120 mins | $40-100 | Architectural, visible steel |
| Concrete Encasement | 50-150mm | 60-240 mins | $80-150 | Nuclear plants, extreme fire risk |
| Board Systems | 25-75mm | 60-180 mins | $50-120 | Data centers, clean rooms |
| Fireproof Cladding | 10-30mm | 30-90 mins | $70-130 | Offshore platforms |
A. Performance Requirements:
ISO 834 (Standard fire curve)
ASTM E119 (Fire resistance tests)
EN 13381-4 (Sprayed coatings)
GB 14907 (Chinese fireproof coatings)
B. Temperature Thresholds:
Critical steel temp: 550°C (ASTM E119)
Intumescent activation: 120-250°C
SFRM protection limit: 1,000°C
Spray-Applied Fireproofing (Most Common):
Density: 250-400 kg/m³
Adhesion strength: ≥0.15 MPa
Curing time: 24-72 hours
Coverage rate: 1.5-3.0 m²/kg @ 25mm
Intumescent Coatings (Aesthetic Solution):
Dry film thickness: 500-5,000 microns
Expansion ratio: 10-50×
Topcoat required: Yes (for weatherproofing)
| Building Type | Required Fire Rating | Typical Solution |
|---|---|---|
| High-rise residential | 90-120 minutes | SFRM 25-40mm |
| Industrial warehouse | 60-90 minutes | Board system 30mm |
| Shopping mall | 120 minutes | Intumescent 2mm |
| Power plant | 180+ minutes | Concrete 100mm |
Material Cost Breakdown:
SFRM: $0.80-1.50/kg
Intumescent: $3-8/m² per coat
Labor: $15-35/m²
Total Installed Costs:
Basic protection (60min): $40-80/m²
High-performance (180min): $120-200/m²
Surface Preparation
SSPC-SP3 power tool cleaning
Profile: 50-75 microns
Primer Application
Epoxy primer (50-80µm)
Cure time: 4-24 hours
Fireproofing Installation
Spray: 2-3 passes
Boards: Mechanical fixing
Paint: 3-5 coats
Quality Control
DFT checks (90-110% spec)
Adhesion testing (pull-off)
Holiday detection
| Method | Inspection Frequency | Common Issues |
|---|---|---|
| SFRM | Annual | Cracking, moisture damage |
| Intumescent | Biennial | Chalking, UV degradation |
| Boards | 5-year | Mechanical damage |
| Concrete | 10-year | Spalling |
BIM-compatible solutions
UL-certified material supply
On-site application teams
3rd party testing coordination
| No | Components | Specification | ||||||
| Embedded Parts | ||||||||
| 1 | Anchor Bolt | M24 | ||||||
| 2 | High Strength Bolt | M20,10.9S | ||||||
| 3 | Common Bolt | M16 | ||||||
| 4 | Galvanized Bolt | M12 | ||||||
| 5 | Shear Nail | M16 | ||||||
| 6 | Tir rod | ∅32*2.5 | ||||||
| Main Steel Structure Parts | ||||||||
| 1 | Steel Column (Q355B) | H550*300*10*16 | ||||||
| 2 | Wind Column (Q355B) | H400*220*6*10 | ||||||
| 3 | Roof Frame Beam (Q355B) | H900~500*220*10*12 H500~650*220*8*12 | ||||||
| 4 | Crane Beam (Q355B) | H650*320/240*10*16/14 | ||||||
| 5 | Tie Bar(Q235B) | ∅168*4.0 | ||||||
| 6 | Horizontal Brace (Q235B) | ∅168*4.0 | ||||||
| 7 | Column Brace (Q235B) | ∅25 | ||||||
| 8 | Angle Brace (Q235B) | L63*5.0 | ||||||
| 9 | Roof Purlin (Galvanized) | Z280*80*20*2.5 | ||||||
| 10 | Wall Purlin (Galvanized) | C250*75*20*2.5 | ||||||
| 11 | Connecting Plate | 6mm-30mm | ||||||
| Other Steel Structure Parts | ||||||||
| 1 | Roof Panel | 50mm Rock wool Sandwich panel | ||||||
| 2 | Wall Panel | 50mm Rock wool Sandwich panel | ||||||
| 3 | Gutter | 2mm Galvanized Steel Plate | ||||||
| 4 | Down Pipe | PVC160 (Including parts) | ||||||
| 5 | Trimming | Color steel 0.5mm Gavanized steel panel | ||||||
