Types of Bracing in Steel Structures - Comprehensive Guide


1. Introduction to Steel Structure Bracing Systems

Steel structure bracing provides essential stability against lateral forces (wind, seismic, crane thrusts). Proper bracing in steel structures improves:
✔ Structural rigidity
✔ Load distribution
✔ Construction safety
✔ Service life extension


2. Primary Bracing Types

A. Horizontal Bracing Systems
(Roof/Diaphragm Bracing)

  • Function: Transfers lateral loads to vertical bracing

  • Common Types:

    • X-bracing (Single/Double diagonals)

    • K-bracing (Concentrically braced frames)

    • Portal bracing (For industrial buildings)

Technical Specs:

  • Material: ASTM A36/A500 Gr.B

  • Connection: Bolted (HSFG) or welded

  • Typical spacing: 6-12m between bays

B. Vertical Bracing Systems
(Wall Bracing)

  • Function: Resists side-sway and overturning

  • Configuration Types:

    • Cross bracing (Most economical)

    • Chevron (V) bracing (Clear doorway access)

    • Eccentric bracing (Seismic energy dissipation)

Key Parameters:

  • Angle: 35°-55° for optimal efficiency

  • Member types: Hollow sections, angles, or channels

C. Specialized Bracing

  • Knee bracing: Low-height diagonal supports

  • Tension-only rods: For light-duty applications

  • Buckling-Restrained Braces (BRB): Seismic zones


3. Technical Comparison Table

Bracing Type Load Capacity Space Intrusion Seismic Performance Cost Index
X-Bracing High Moderate Good $$
Chevron Medium-High Low Fair $$$
Eccentric High High Excellent $$$$
Portal Very High Very Low Good $$

4. Bracing Connection Details

Critical Components:

  • Gusset plates (8-25mm thickness)

  • Slotted holes for adjustment

  • Moment-resisting connections

Installation Standards:

  • AISC 341 (Seismic)

  • EN 1993 (Eurocode)

  • GB 50017 (China)


5. Project Application Guide

For Warehouses:

  • Recommended: Single-diagonal roof bracing + portal frames

  • Steel grade: Q235B with hot-dip galvanizing

For High-Rises:

  • Optimal: Eccentric bracing with BRBs

  • Connection: Welded box sections

For Bridges:

  • Special: K-bracing with fatigue-rated details

  • Material: ASTM A709 Gr.50


6. Quality Control

  • Dimensional tolerance: ±3mm

  • Non-destructive testing: UT for critical welds

  • Pre-installation trial fitting
