Liyou Steel designs high-quality agricultural steel buildings for barns, equipment storage, poultry houses, and crop storage. Our pre-engineered steel structures provide superior strength, fast construction, and low maintenance, making them the ideal choice for modern farming.
| Quantity: | |
|---|---|
✔ Weather-Resistant – Withstands heavy snow (up to 1.5 kN/m²), strong winds (200 km/h+), and corrosion.
✔ Spacious & Column-Free – Clear-span designs (up to 40m) for uninterrupted machinery movement.
✔ Fast Installation – Prefabricated components reduce construction time by 50%+.
✔ Low Maintenance – Galvanized steel resists rust, mold, and pests.
✔ Customizable – Adjustable ventilation, insulation, and door systems.
| Type | Best For | Key Features |
|---|---|---|
| Equipment Sheds | Tractors, harvesters, tools | Wide doors, heavy-duty flooring |
| Livestock Barns | Cows, horses, poultry | Ventilation, insulated roofs |
| Grain Storage | Wheat, corn, soybeans | Airtight seals, pest-proof |
| Hay & Feed Storage | Dry storage needs | UV-resistant roofing |
| Greenhouses | Hydroponics, nurseries | Light-transmitting panels |
| Feature | Specification |
|---|---|
| Frame Material | Q355B Steel (Galvanized) |
| Roof/Wall Options | Corrugated steel, insulated panels, or PVC |
| Door Systems | Sliding, roll-up, or bi-fold (up to 15m wide) |
| Ventilation | Ridge vents, side curtains, exhaust fans |
| Flooring | Concrete, compacted gravel, or slatted |
| Size | Price Range (USD) |
|---|---|
| Small (10m×20m) | $15,000 – $25,000 |
| Medium (20m×30m) | $30,000 – $50,000 |
| Large (30m×50m+) | $60,000 – $120,000+ |
(Cost varies with insulation, doors, and customization.)
✔ Insulation (for temperature-sensitive storage)
✔ Solar Panel Roofs (reduce energy costs)
✔ Automated Feeding/Ventilation Systems
✔ Fireproofing (for grain storage)
✔ Dairy Barn in Canada – Insulated for -30°C winters
✔ Poultry House in Vietnam – 50,000-bird capacity
✔ Grain Silo in Kenya – 500-ton storage
✅ 20+ Years in Agricultural Steel Buildings
✅ CE/ISO Certified Manufacturing
✅ Free 3D Design & Quote
✅ 10-Year Warranty on Structure
Tell Us: Size, location, intended use
Receive:
3D Design Plans
Material & Cost Breakdown
Delivery Timeline
Build a stronger, smarter farm today!
Place of Origin: | Product Name: |
Foshan, China (Mainland) | Steel Frame House |
Material: | |
Q345 Q235 H Section Steel, C/Z Section Steel, Square Tube etc. | |
Standard: | Type: |
GB | Steel Structure Frame |
Size: | Color: |
Up to Customer's Requirement | Graywhite, Blue, Red, etc.. |
Roof & Wall Material: | Insulation: |
Sandwich Panel | EPS, Rockwool, Glass wool, PU etc.. |
Door & Windows: | Technology: |
Steel Door, Aluminum Sliding Window, PVC Window | Welded steel, Hot Rolled Steel |
Drawing Design: | Keywords: |
AutoCAD, Tekla Structure, Vertex BD, SketchUp etc. | Big Metal Building Homes |
Components | Specification |
Anchor Bolt | M30 |
High Strength Bolt | M20，10.9S |
Common Bolt | M16 |
Galvanized Bolt | M12 |
Shear Nail | M16 |
Steel Column(Q345B) | HN600X200X10X15 |
Steel Column(Q345B) | HN300X150X6.5X9 |
Roof Column(Q345B) | HN350X175X6X9 |
Floor Main Beam(Q345B) | HN500X200X9X14 |
Floor Second Beam(Q345B) | HN350X175X6X9 |
Stair | ∅16-bar+2.5mm Chequered Plate |
Tie Rod | ∅89*3.0 |
Horizontal Support | ∅16 |
Roof Purlin（Galvanized) | C180*60*20*2.0 |
Wall Purlin（Galvanized) | C180*60*20*2.0 |
Connecting Plate | 6mm～20mm Steel Sheet |
Paint | 2 Times Spray Paint |
Roof Tile- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
FRP Skylight Panel | Fiber Glass Reinforced Polyester |
Outside Wall Panel -- EPS Sandwich panel | 50mm Color Steel Thickness: 0.426 |
Floor Decking | 1.5mm Galvanized Steel Sheet |
Stair Handrail | 口80*40+口40+口30+口20 |
Gutter | 2.0mm Galvanized Gutter |
Down Pipe | ∅110PVC |
Trimming | 1.0mm Galvanized Steel Sheet |
Steel Structure Building Applications
Livestock Shed, Garage, Plant, Warehouse, Workshop, Office Building, Hotel Building, Commercial Building , Residential House, Airplane Hangar, Outdoor Stadium Shed, Labour Camp, School, Exhibition Hall, Logistics Park, Refrigeration House, Resort, Dormitory Building, Shopping Mall.
01 Customized Design
Offer professional building planning & drawing, and suitable steel components according to your requirements.
02 Quality Assurance
● Strict quality control
● Safe packing
● Quality inspection before shipment
03 After-sales service
● Installation instruction on site
● Installation technical team backup
● Timely communication by Email & Phone
