Base Plate in Steel Structure



Base Plates for Steel Structures – High-Performance Connection Solutions

Product Overview

LiYou Steel manufactures precision-engineered base plates in steel structures that provide critical load transfer between steel columns and concrete foundations. Our steel column base plates are custom-designed to meet project-specific requirements for:

✔ High-rise buildings
✔ Industrial facilities
✔ Bridge piers
✔ Equipment foundations
✔ Seismic-resistant structures



Availability:
Quantity:
Inquire

  • Steel

  • Online technical support

  • Office Building

  • Guangdong, China

  • Steel Structure

  • 3 years

  • total solution for projects

  • Office

  • Modern

  • CE Certification

  • Industrial Commercial

  • C.Z Shape Steel Channel

  • Sliding Door

  • Customized Color

  • Sandwich Panel Optional

  • Aluminum Alloy Sliding Window

  • SAP2000/AutoCAD /PKPM /3D3S/TEKLA

  • Hot Dip Galvanized

  • 25-60 days

  • Single item

  • 1X1X1 cm

  • 1.000 kg

Technical Specifications

1. Material Options

  • Plate Material:

    • Q235B/Q355B (GB Standard)

    • ASTM A36/A572 Gr.50

    • EN 10025 S275/S355

  • Anchor Rods:

    • Grade 4.6/8.8 (ISO 898-1)

    • Stainless steel (A4-80) available

2. Standard Features

  • Thickness range: 20mm-100mm

  • Size tolerance: ±2mm (EN 1090-2)

  • Hole positioning accuracy: ±1mm

  • Surface preparation: Sa 2.5 blasted

3. Customization Options

  • Slotted holes for adjustment

  • Shear keys for heavy loads

  • Leveling nuts and washers

  • Galvanized or painted finishes

Design Capabilities

Our engineering team provides:

  • Load Analysis:

    • Axial compression/tension

    • Moment resistance

    • Shear capacity

  • Code Compliance:

    • AISC Design Guide 1

    • EN 1993-1-8

    • GB 50017

  • BIM Integration:

    • Tekla Structures models

    • Revit families

    • DXF fabrication drawings

Quality Assurance

Manufacturing Process Control

  1. CNC plasma cutting (±0.5mm accuracy)

  2. Drill/mill machining (H7 hole tolerance)

  3. Surface treatment (40-80μm zinc coating)

  4. 100% dimensional inspection

Certifications

  • ISO 9001:2015

  • EN 1090 EXC3

  • CE Marking

Project Gallery

Recent Applications

  1. Shanghai Office Tower

    • 1200×1200mm base plates

    • 60mm thickness with shear lugs

    • Designed for 15,000kN axial load

  2. Philippines Power Plant

    • Circular base plates (Φ800mm)

    • 316 stainless steel anchors

    • Seismic detailing per ASCE 7


Specification
item
value
Material
Steel
After-sale Service
Online technical support
Application
Office Building
Place of Origin
China
Guangdong
Product Type
Steel Structure
Warranty
3 years
Project Solution Capability
total solution for projects
Use
Office
Design Style
Modern
Certification
CE Certification
Application Fields
Industrial Commercial
Purlin
C.Z Shape Steel Channel
Door
Sliding Door
Color
Customized Color
Wall and Roof
Sandwich Panel Optional
Window
Aluminum Alloy Sliding Window
Drawing Design
SAP2000/AutoCAD /PKPM /3D3S/TEKLA
Surface treatment
Hot Dip Galvanized
Delivery time
25-60 days
Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
  00:00     02:10
Guangdong Li You Steel Structure Engineering Co., Ltd. is a facility that specializes in the production of steel components used in the construction of buildings, bridges, and other structures. We also specialize in designing, producing, marketing, and building steel structure workshops, modular homes, and light steel villas. Our factory typically employs advanced machinery and skilled workers to produce steel beams, columns, trusses, and other components to exacting standards. We may also offer design and engineering services to help clients create custom steel structures that meet their unique needs. With its high strength and durability, steel has become a popular material for construction, making steel structure factories an important part of the global manufacturing industry. Our team uses special tools like cranes and welding machines to carefully install the steel products. Safety is our top priority, and we work hard to make sure everything is secure and stable. We're excited to create something amazing with our steel structures, and we can't wait to show you the finished product! Look for SGS, look for us.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2022,sell to Domestic Market(40.00%),South America(17.00%),Southeast Asia(15.00%),North America(10.00%),Africa(5.00%),South Asia(2.00%),Eastern Asia(2.00%),Oceania(2.00%),Central America(2.00%),Mid East(2.00%),Western Europe(1.00%),Southern Europe(1.00%),Eastern Europe(1.00%). There are total about 51-100 people in our office.

  2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

  3.what can you buy from us?
Steel Structure Building, Steel Structure Warehouse, Steel Structure Workshop, Multi-story Steel Structure, Steel Structure Villa

  4. why should you buy from us not from other suppliers?
Guangdong Li You Steel Structure Engineering Co., Ltd. is a facility that specializes in the production of steel components used in the construction of buildings, warehouse,workshops,bridges, and other structures.

  5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
